fish smoking machine/meat smoking machine/fish smoker/sausage smoking machine/gas smoking oven
Features of fish smoking machine :
1.Import Germany technology
2. Types:electric heating smoke house,baking smoke house,steam smoke house,refrigerating smoke house,heat conduction oil house
3.With low energy consumption,heating up fast , cooking,drying,baking,cold smoked,hot smoked,spray cooling and other functions
4.Users can process according to the different processing requirement to achieve automatic control,to curing and sterilization
5.The circulation system is composed of smoked chasis,automatic process control,smoke generators,smoke car
6.The key components is the steam pipes,heat exchanger(baking functionlity requires installation of electric pipe)and outlet channels . The mixture of hot air and the fume inside become vortext region under the effect of two groups of circle fans ,so that the mixture gas through the meat hanging in the smoke box enevtly in appropriate rate to curing and sterilization
7.With anti-dust clouds,anti-magnetic.anti-salt enable the machine more secure and reliable
8.The smoke generator include wood particles and wood crumb.The wood particles generator reliable and with large amount of smoke,not easy to get open fire,do not advance the ignition
Technical parameter of fish smoking machine :
model |
YXX-120 |
YXX-250 |
YXX-500 |
YXX-750 |
YXX-1000 |
Capacity(kg/time) |
120 |
250 |
500 |
750 |
1000 |
Voltage (v) |
380 |
380 |
380 |
380 |
380 |
Motor(kw) |
3 |
6 |
9 |
12 |
15 |
Temperature(°) |
<100 |
<100 |
<100 |
<100 |
<100 |
Steam pressure(mpa) |
0.1-0.2 |
0.1-0.2 |
0.1-0.2 |
0.1-0.2 |
0.1-0.2 |
Water pressure(mpa) |
0.2 |
0.2 |
0.2 |
0.2 |
0.2 |
Feed cart size(m) |
1*1.03*1.8 |
1*1.03*1.8 |
1*1.03*1.8 |
1*1.03*1.8 |
1*1.03*1.8 |
Machien size(m) |
1.29*2.2*1.96 |
1.29*2.2*3 |
2.36*2.2*3 |
3.43*2.2*3 |
4.49*2.2*3 |
Machine weight(kg) |
800 |
1600 |
2200 |
2600 |
2800 |
Pictures of fish smoking machine :
Final products:
Contact information:
Contact :Larry He
Skype:Larry.he3
QQ:2746542104
Tel:86-18939526905
Fax:0086-371-53392380
Email:larry@aslanjixie.
com
Any questions if you have, please do not hesitate to tell us.
Your satisfaction is what we are always struggling for!
