fish bone separator/fish bone separating machine/fish meat bone separating machine/fish meat saparator
Introduction of automatic fish bone separator
1. This machine is specially used to separate the fish meat, the bones and the tendon, which can
improve the utilization rate of raw materials and also save the labor cost.
2. The whole machine is made of high quality stainless steel, it is anti-corrosive, which meets the
national food hygiene standards.
3. The fish flesh separator is used for the collection and extraction of the fish flesh.
4. Fast removing and separating speed, high capacity, proper for fish meat ball making,fish meat
collecting, fish meat patty making, fish meat food processing, the final fish me at is pure and fresh.
5. The fish meat go into the drum through holes on the drum, the holes diameter is 2mm, 3.2mm and 3.5mm, when the drum rotates, the crushed fish meat come out from the outlet of drum. The fish bone will come out from another outlet.
Working principle
1. Get rid of fish head and tripe. Big fish, split in half.
2. Put into the water to rinse,avoiding the separated flesh fish being polluted by fish impurities.
3. Put slices of fish meat into the hopper (The division face towards adopting tube, the backside pressed close to rubber belt.).
Technical parameter of automatic fish bone separator
Model |
Tape width |
Wire speed |
Voltage |
Capacity |
Power |
Size(mm) |
YGJ-200 |
200mm |
36r/min |
380v |
250kg/h |
2.2kw |
900x750x1150mm |
YGJ-300 |
300mm |
36r/min |
380v |
650kg/h |
3kw |
900x750x1250mm |
Photos of automatic fish bone separator
Final products
