Industrial tunnel type continuous microwave machine for Licorice Chip Dryer
I.Structure
The whole machine consists of stainless steel, and it adopts the combined and removable assembly
module in several parts:
A.The main body frame; B.Conveying part; C.Microwave generator parts;
D.Microwave heating cabinet parts; E.Microwave preventing leakage parts etc.
II. Feature
1)Drying fast and uniformly.
2)Big capacity.
3)Save labour and energy.
4)Tunnel type design,24 hours continuous production.
5)Drying and sterilizing simultaneously
6)Low temperature sterilization, keep original nurtrition,color,tatse.
IV. Application
This equipment are widely used for drying and sterilizing powder, granular, flakes or colloidal form foods, nutritional health products, grain, agricultural and sideline products(rice, cornmeal), bamboo shoot, tea(wild chrysanthemum flower, broadleaf holly leaf, lotus leaf, green tea, black tea, puer tea), ginseng, mushroom, agaric, ganoderma, vegetables and fruits(spinach, carrot, parsley, onion, mango slice, apple slice, lemon slice, kiwi slice, banana slice etc.), preserved fruits, red jujube, non-fried(oil saving) instant noodles, noodles, cookie, biscuit, rice powder noodles, chicken jerky, beef jerky, preserved meat, dried fish, seafood(seaweed, sea cucumber, laver, kelp, sardine, shrimp, abalone etc.), pickles, spices(pepper powder, Chicken essence, beef essence, pork essence, yeast extract, seafood extract, seafood soup essence, seafood soup powder, spareribs soup pure, spareribs soup powder, spice, chili powder, ginger powder, garlic powder, aniseed, cinnamon, angelica, cumin, cassia bark, fennel etc.), egg yolk powder, jam, a variety of small packaging and pet food mildew sterilization preservation.
V. Reference technical parameters
Power: |
3 phases and 5 wires. 380V±10% 50Hz±1% |
Microwave output frequency: |
2450±50MHZ |
Microwave power input: |
≤28KVA |
Microwave power output: |
≥20KW |
Ambient temperature: |
5-40°C |
Relative humidity: |
≤80% |
Position of input: |
At the top of the microwave cabinet |
Microwave system cooling way: |
Magnetron(Air cooling) |
Conveying speed: |
0-10m/min(adjustable) |
Temperature control range: |
0-200°C (adjustable) |
Dehydrated efficiency |
20~28(kg/h) |
Belt width: |
700mm(we can change according your requirement) |
Overall dimensions(L*W*H): |
About 9400*840*2050 mm |
Life of magnetron: |
>8000h |
|
Microwave leak: Accord with the national standard GB10436—89 of China Equipment safety standards:(My company's standard≤1MW/CM2) Equipment safety:accord with GB-5226Electrical safety standardaccord with a country GB16798-1997 Food. | |
VI.Reference picture
V. Guarantee and after-sales service
For the whole equipment,warranty is 12 months,within 12 months,if have equipment quality
problems,we will provide accessories freely. After the expiration of the warranty period,if have
spare parts problem,we only receive the cost of required replacement parts.We commit we will
provide free technical support of equipment all whole life.
If you have any problem about our equipment, please feel free to contact me
