CE Newest Type Wood Dryer, Wood Chip Dryer, Sawdust Dryer

CE Newest Type Wood Dryer, Wood Chip Dryer, Sawdust Dryer photo-1
US$ 3,500 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Drying Oven
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Drying Oven
Place of Origin Henan, China
Brand Name NMB
Model Number wood chip dryer AS3770
Voltage 380v,220v,240v,etc
Power(W) 4+1.5kw
Dimension(L*W*H) 8500*1500*3500
Weight 1000kg
Certification CE,ISO,CNCA
Warranty 24 MONTH
After-sales Service Provided Engineers available to service machinery overseas

CE newest type wood dryer, wood chip dryer, sawdust dryer



wood chip dryer  Specification

Type(mm)

Indiclination

(%)

Rotation speed

(r/min)

Input temperature (ºC)

Motor power

(kw)

Output

(t/h)

Weight

(t)

Φ600×6000

3-5

3-8

≤700

3

0.5-1.5

2.9

Φ800×8000

3-5

3-8

≤700

4

0.8-2.0

3.5

Φ800×10000

3-5

3-8

≤700

4

0.8-2.5

4.5

Φ1000×10000

3-5

3-8

≤700

5.5

1.0-3.5

5.6

Φ1200×10000

3-5

3-8

≤700

7.5

1.8-5

14.5

Φ1200×12000

3-5

3-8

≤700

11

2-6

14.8

Φ1500×12000

3-5

2-6

≤800

15

3.5-9

17.8

Φ1800×12000

3-5

2-6

≤800

18

5-12

25

Φ2200×12000

3-5

1.5-6

≤800

18.5

6-15

33

Φ2200×18000

3-5

1.5-6

≤800

22

10-18

53.8

Φ2200×20000

3-5

1.5-6

≤800

30

12-20

56

Φ2400×20000

3-5

1.5-5

≤800

37

18-30

60

Φ2800×15000

3-5

1.5-5

≤800

40

20-35

72.5

Φ2800×18000

3-5

1.5-5

≤800

40

25-35

75

Φ3000×20000

3-5

1.5-5

≤800

55

28-40

78

Φ3000×25000

3-5

1.5-5

≤800

75

32-45

104.9



wood chip dryer Drying Equipment Name hot air dryer

CE newest type wood dryer, wood chip dryer, sawdust dryer

wood dryer Drying Equipment Heating way use coal,wood,briquette any type buring material

CE newest type wood dryer, wood chip dryer, sawdust dryer

wood chip dryer  features

Sawdust Dryer is suitable for dry the grain, sawdust, etc small granular materials.

It can dry the raw materials quickly and with higher capacity.

1. For raw materials with heavy humidity which is above 12%, you need to install a Dryer

before further processing. This Type Dryer can reduce the humidity of wood materials below

12% per time.

2. It is professionally designed for drying different kinds of wood sawdust. It has advantages

of high capacity low cost.

3.Size of Input material:< 3 & < 5mm

4.Thisis handling by bringing it into direct contact with a heated gas. It is made up of a large,

rotating cylindrical tube,The dryer slopes slightly so that the discharge end is lower than the

material feed end in order to convey the material through the dryer under .

5.It's structure including main tube body, hot air stove, cyclone dust collectors, spiral feeder,

draught fan,motor ,  distribution box and conveyor.



sawdust dryer Drying Equipment Final finished moisture less 8 %

CE newest type wood dryer, wood chip dryer, sawdust dryer

wood power dryer photos



wood chip dryer Drying Equipment Capacity 300-400kg per hour

CE newest type wood dryer, wood chip dryer, sawdust dryer

Briquette or  pellet



wood dryer Drying Equipment Size of input 1-5mm

CE newest type wood dryer, wood chip dryer, sawdust dryer

sawdust dryer Drying Equipment Temperature of Hot Air 180° C -250° C

CE newest type wood dryer, wood chip dryer, sawdust dryer

Payment Terms

 T/T,L/C OR WESTERN UNION

Packing Information

International standard wood fumicated box

wood power dryer more photos



wood chip dryer Drying Equipment Consumption of wood waste 10-15kg per hour

CE newest type wood dryer, wood chip dryer, sawdust dryer

wood dryer Drying Equipment Max moisture 50% hot air dryer

CE newest type wood dryer, wood chip dryer, sawdust dryer

sawdust dryer Drying Equipment Package wood box

CE newest type wood dryer, wood chip dryer, sawdust dryer

Welcome to contact us !!

wood chip dryer Drying Equipment Usage for different farm waste such as sadust,wood chips,and other wastes
