CNC Circular Tube Bending Machine

CNC Circular Tube Bending Machine thumbnail-1
CNC Circular Tube Bending Machine photo-1
US$ 5,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
NMB
Contact Supplier Request Quote Chat Now
Henan Name Brand Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Henan, China
Brand Name NMB
Model Number NMB-75CNC AS5583
Machine Type Pipe and Tube Bending Machine
Raw Material Pipe
Material / Metal Processed Stainless Steel
Power Hydraulic
Automation Automatic
Extra Services End Forming
Certification Other, CE,ISO9001:2008
After-sales Service Provided Overseas service center available

CNC circular tube bending machine :



CNC circular tube bending machine Bending Machines Model NM75CNC

CNC circular tube bending machine

 Introduction of our machine:

Our this kind machine can be classified into CNC pipe bending machine, hydraulic bender and other kinds. It is an equipment used to power construction, construction of roads and railway, boiler, bridge, ship, furniture, decoration and other fields that is related to the pipe laying and building. It has features of multi-function, reasonable construction,and easy operation. It enjoys a good market in the worldwide!

Features of our machine:

1. Fully automatic, is very easy to use and operate;
2. Equipped with 3 programmable axis;
3. Hydraulic pressure die assist for every bending stack;
4. Wiper, clamping and pressure die seats;
5. Centralized greasing system for moving areas;
6. Electric cabinet cooling fan;
7. Touch screen system
8. CNC 2 servo controlled axes with NC hydraulic bending

Technical parameter of our machine:


Model

NMB38CNC

NMB50CNC

NMB75CNC

Max.bending ability(mm)

38×1.5 A3

50×1.5 A3

75×1.5 A3

Range of bending radius (mm)

25-200

35-200

50-280

Toptight formation(mm)

55

65

100

Feeding accuracy(mm)

0.1

0.1

0.1

Feeding speed(m)

1.1

1.1

1.1

Max.bending angel

185°

 185°

190°

Bending precision

0.1°

0.1°

0.1°

Bending speed°/sec

65°

44°

24°

Accuracy of angel

0.1°

0.1°

0.1°

Cormer speed°/sec

120°

120°

120°

Power source

380V,50Hz

380V,50Hz

380V,50Hz

Control valve voltageV

2

24

24

Total power(KW)

 6.0

8.0

10.0

Oil Pump Power(KW )

4.0

5.5

7.5

Spare parts of our machine:

The spare parts of our machine include: forming die, pressure die,clamp die, wiper die(optional), ball

mandrel(optional).

Different shape of final products for your reference:

CNC circular tube bending machine Bending Machines Processing type: pipe bender dies

CNC circular tube bending machine



CNC circular tube bending machine Bending Machines Total power 6kw

CNC circular tube bending machine

 Other pipe benders pictures of our factory:



CNC circular tube bending machine Bending Machines Feeding accurance 0.1mm

CNC circular tube bending machine

Machine matched with pipe bender machine:

CNC circular tube bending machine Bending Machines Opration type: CNC

CNC circular tube bending machine
