China professional small corn milling machine,
corn milling machine for kenya, rice and corn
milling machines
corn milling machine Flour Mill Raw material stalk,cotton stalk,maize, peant, peanut, corn stems,grain,corn...
Features and advantage:
|
1. High ratio of crushing. 2. Equal product granularity. 3. Simple structure, easy operation. 4. Convenient requirement. 5. Low consumption. 6. Working by diesel engine or motor.
|
|
1.This kind of corn hammer mill is smashing equipment for processing block material or rod -like material in to forage and animal feeds. it is mainlysuitable for corn, corn stalk, peanut shell, bean stalk and so on.
2.Its working principle is material from the hopper into the crushing chamber,there have been high-speed rotating hammer crushing blow, under the action of centrifugal force to break the material along the outer edge of the rotor, continuous film by the hammer, tooth plate, screen film extrusion, collision, combat, rubbed and was quickly crushed, crushed powder after the centrifugal rotor by the pressure and suction force of the fan sent outside the aircraft through the sieve, sieve the powder through repetition but on top process until the machine through the sieve was sent to the far outside. |
China manufacture corn/maize flour milling
machine Specification
Item |
Specification |
Model |
NMB-36 |
Overall dimension: |
1200*650*1200mm |
Overall weight |
200Kg |
Rotor diameter |
360mm |
Matched power |
5.5-7.5KW/380V |
Diesel engine |
10HP |
Speed of main spindle |
4600r/min |
Hammer speed |
86.7M/S |
Size of input granules |
202mm |
Clearance between hammer & sieve surface |
10mm |
Hammer No. |
12 |
Hammer arrangement |
staggered parallel arrangement |
Sieve disc width |
200mm |
Sieve disc cornerite |
180o |
Sieve pore specification |
0.5mm – 5mm |
Fan impeller diameter |
260mm |
|
Productivity for sieve pore diameter 2mm: Corn: 1000-15000KG Corn stalk: 80-150KG Peanut shell: 300-500KG Bean stalk: 130-230KGDifferent grain and crops has different productivity Other type machines (different output) are available. | |
Our this model machine working with electric and diesel
motor picture
corn milling machine for kenya Flour Mill Corn 1000-1500kg/h
rice and corn milling machines Flour Mill Cornstalk 100-200kg/h
Our factory machine working processing
corn milling machine Flour Mill Peanut shell 400-500kg/h
Factory show for one buyers of 2*40GP containers
corn milling machine for kenya Flour Mill sieve mesh 2mm
Deleivery Picturs with our company brand NMB
rice and corn milling machines Flour Mill Power 15kw
About our service:
|
1.Our machine motor has one year warrenty,durning this time if the motor don't work we will send the new one to you for free. 2.Whenever you have need of the machine spare part,we can supply you at once! 3.And you can consult with us for machine knowledge at any time by email or tel,whenever is ok for us! |
Our machine is hot selling in many countrys,if
you have any needs of them, please feel free
to contact us!!!
corn milling machine Flour Mill Mainshaft speed 3200rpm
