Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > China Manufacture Maize/corn Flour Milling Plants

China Manufacture Maize/corn Flour Milling Plants

US$ 1,150 - 3,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Henan, China

Brand Name:

NMB

Contact Supplier Request Quote Chat Now

Henan Name Brand Machinery Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Henan, China

Brand Name NMB

Model Number NMB-36 AS3175

Production Capacity 500-650kg/h

Voltage 380V/50HZ/3Phase

Power(W) 5.5kw

Weight 200kg, 200kgs

Dimension(L*W*H) 1200*650*1200mm

Certification ISO

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

China manufacture maize/corn flour milling plants

Features and advantage:

1. High ratio of crushing

2. Equal product granularity

3. Simple structure, easy operation

4. Convenient requirement

5. Low consumption

6. Working by diesel engine or motor

This kind of corn hammer mill is smashing equipment for processing block material or rod -like material in to forage and animal feeds. it is mainly suitable for corn, corn stalk, peanut shell, bean stalk and so on.

Its working principle is material from the hopper into the crushing chamber, there have been high-speed rotating hammer crushing blow, under the action of centrifugal force to break the material along the outer edge of the rotor, continuous film by the hammer, tooth plate, screen film extrusion, collision, combat, rubbed and was quickly crushed, crushed powder after the centrifugal rotor by the pressure and suction force of the fan sent outside the aircraft through the sieve, sieve the powder through repetition but on top process until the machine through the sieve was sent to the far outside.

China manufacture maize/corn flour milling plants Specification

Item	Specification
Model	NMB-36
Overall dimension:	12006501200mm
Overall weight	200Kg
Rotor diameter	360mm
Matched power	5.5-7.5KW/380V
Diesel engine	10HP
Speed of main spindle	4600r/min
Hammer speed	86.7M/S
Size of input granules	202mm
Clearance between hammer & sieve surface	10mm
Hammer No.	12
Hammer arrangement	staggered parallel arrangement
Sieve disc width	200mm
Sieve disc cornerite	180^o
Sieve pore specification	0.5mm – 5mm
Fan impeller diameter	260mm
Productivity for sieve pore diameter 2mm: Corn: 500-650KG Corn stalk: 80-150KG Peanut shell: 300-500KG Bean stalk: 130-230KGDifferent grain and crops has different productivity Other type machines (different output) are available.
