Series One:
Lead Edge Automatic Die Cutting Machine With Stripping Section
Specifications:
|
| ||||
| Model | 1300Q | 1500Q | 1650Q | 1700Q |
| Max.paper size | 1330*980mm | 1500*1100mm | 1650*1200mm | 1700*1200mm |
| Min.paper size | 550*480mm | 600*500mm | 650*500mm | 700*500mm |
| Max.cutting size | 1300*960mm | 1480*1080mm | 1630*1180mm | 1680*1180mm |
| Max.cutting pressure | 250*10000N | 320*10000N | 400*10000N | 400*10000N |
| Stock range | 1mm<= corrugated board <=8.5mm | |||
| Cutting precision | ±0.5mm | ±0.5mm | ±0.5mm | ±0.5mm |
| chanical speed | 4800 s/h | 4800 s/h | 4500 s/h | 4200 s/h |
| Cutting rule height | 23.8mm | 23.8mm | 23.8mm | 23.8mm |
| Pressure adjusting range | ±1.5mm | ±1.5mm | ±1.5mm | ±1.5mm |
| Min.front margin | 10mm | 10mm | 10mm | 10mm |
| inner chase size | 1330*980mm | 1500*1100mm | 1650*1200mm | 1700*1200mm |
| Total power |
32kw (Double-servo without air compressor) |
35.5kw (Double-servo without air compressor) |
39kw (Double-servo without air compressor) |
39kw (Double-servo without air compressor) |
| Machine Dimension |
9520*4550*2440mm (include the work platform) |
10075*5170*2460mm (include the work platform) |
10575*5372*2550mm (include the work platform) |
10575*5522*2550mm (include the work platform) |
| Machine Dimension |
9020*2470*2400mm (exclude the work platform die change frame) |
9505*2820*2460mm (exclude the work platform die change frame) |
10005*2920*2550mm (exclude the work platform die change frame) |
10005*2970*2550mm (exclude the work platform die change frame) |
| Total weight | ~28t | ~31t | ~38t | ~40t |
Advantage:
Feeding Section: High speed and precision lead edge feeder, scratches can be advoided during feeding. Frequency conversion control wind volume adjustment, can adopt to different requirement of the different paper. Wind suction area can adjust according to the paper size with high-power fan.
Feed table: Adopts left and right push side lay to fulfill different printing registration requirement. adjustable rubber wheel and brush wheel to ensure precise positioning to enter into front and side lay.
Die cutting Section: Adopts pneumatic lock-up system on die cutting chase to increase efficiency. Computerized control display system and 3D touch screen operation can immediately trace and visualize machine status and possible machine stop causes. Equipped with 3 cam index box device and overloading protection clutch for perfect registration.
Stripping Section: Double-action movement structure with upper and lower stripping frame facilitates die changes, motorized upper frame suspending hoist. Male/female die are available for different stripping jobs. Equipped with full stripping device for higher production efficiency. Adopts centerline registration system, reduce die change time, accurate positioning can increase production feeiciency.
Delivery section: Adopt non-stop delivery system to insure stable and fast paper delivery. Safety photoelectric device to insure tidy paper delivery.
Series Two:
Lead Edge Automatic Die Dutting Machine with Semi-stripping Section
Specifications:
| ||||
| Model | 1160Q | 1300Q | 1450Q | 1620Q |
| Max.paper size | 1180*900mm | 1330*980mm | 1480*1080mm | 1650*1210mm |
| Min.paper size | 500*480mm | 550*480mm | 600*500mm | 650*500mm |
| Max.cutting size | 1160*880mm | 1300*960mm | 1450*1050mm | 1620*1190mm |
| Max.cutting pressure | 200*10000N | 250*10000N | 300*10000N | 300*10000N |
| Stock range | corrugated board 1-7MM | 1mm<= corrugated board <=8.5mm | ||
| Cutting precision | ±0.5mm | ±0.5mm | ±0.5mm | ±0.5mm |
| chanical speed | 4200 s/h | 4200 s/h | 4000 s/h | 4000 s/h |
| Cutting rule height | 23.8mm | 23.8mm | 23.8mm | 23.8mm |
| Pressure adjusting range | ±1mm | ±1mm | ±1mm | ±1mm |
| Min.front margin | 8mm | 8mm | 8mm | 8mm |
| inner chase size | 1190*910mm | 1330*990mm | 1480*1080mm | 1646*1220mm |
| Total power |
22.7kw (exclude air compressor) |
26.2kw (exclude air compressor) |
33.7kw (exclude air compressor) |
37.2kw (exclude air compressor) |
| Machine Dimension |
7275*4280*2195mm (include the work platform) |
7645*4645*2220mm (include the work platform) |
8195*4856*2235mm (include the work platform) |
8896*5241*2295mm (include the work platform) |
| Machine Dimension |
7125*2385*2195mm (exclude the work platform die change frame) |
7430*2600*2220mm (exclude the work platform die change frame) |
7750*2670*2235mm (exclude the work platform die change frame) |
8170*2840*2295mm (exclude the work platform die change frame) |
| Total weight | ~17t | ~20t | ~22t | ~27t |
Series Three:
Lead Edge Feeder Automatic Die Cutting Machine With Stripping Section(High-Speed Machine)
| Model | 1500G | 1650G |
| Max.paper size | 1500*1100mm | 1650*1200mm |
| Min.paper size | 600*500mm | 650*500mm |
| Max.cutting size | 1480*1080mm | 1630*1180mm |
| Max.cutting pressure | 320*10000n | 450*10000n |
| Stock range | 1mm<=corrugated board<=9mm | 1mm<=corrugated board<=9mm |
| Cutting precision | ±0.5mm | ±0.5mm |
|
chanical speed |
5500 s/h | 5500 s/h |
| Cutting rule height | 23.8mm | 23.8mm |
| Pressure adjusting range | ±1.5mm | ±1.5mm |
| Min.front margin | 10mm | 10mm |
| inner chase size | 1500*1100mm | 1660*1210mm |
| Total power | 37kw(exclude air compressor) | 37kw(exclude air compressor) |
| Machine Dimension |
10290*5270*2460mm (include the work platform) |
10575*5372*2550mm (include the work platform) |
| Machine Dimension |
9720*2920*2460mm (exclude the work platform die change frame) |
10005*2920*2550 (exclude the work platform die change frame) |
| Total weight | ~31t | ~38t |
