Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > 8ton XN90-8 Mini Hydraulic Crawler Excavator

8ton XN90-8 Mini Hydraulic Crawler Excavator

Name: 8ton XN90-8 Mini Hydraulic Crawler Excavator
Brand: HEANG AN
SKU: 137621869
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

HEANG AN

Model Number:

LD90-8

Weifang Heng An Imp& Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name HEANG AN

Model Number LD90-8

Condition New

Moving Type Crawler Excavator

Operating Weight 8400KGS

Bucket capacity 0.35-0.4 m3

Maximum Digging Height 6500mm

Maximum Digging Depth 4300mm

Machine Weight 8000KGS

Max Digging Radius 6400mm

After-sales Service Provided Overseas service center available

mini excavator

Engine
Model	YUCHAI brand YC4D80-T21) or CUMMINS
No. of cylinders	4 cyliners in line, water cooled
Bore and stroke	108x115(mm)
Displacement	4.214L
Rated power	56kw/2200rpm
Max. torque	275N.m
Compression ratio	17.5:1
Lubricating method	Pressure lubrication and splash lubrication
Fuel consumption	≤ 235 g/kwh
Engine oil consumption	≤ 0.8%
Travel system
Travel motor	JEIL brand (Imported from Korea)
Model	JMV-47/27-01-VBC-RJ-53
Travel brake	hydraulic disc brake
Parking brake	oil release
No. of track shoes	2x40
Width of track shoe	452 mm
Distance between two track shoes	1430 mm
Travel speed	3 (Km/h)
Maximum tractive force	62 KN
Grade ability	70% (30 degree)
Ground clearance	420mm
Balance weight to ground	770mm
Hydraulic system
Main hydraulic pump	SKS (saikesi)
Model	SPVC90RC08
Type	variable double-piston pump
Max. discharge flow	90 ml
Speed	2300 rpm
Pressure	28 Mpa
Pilot control pump	STUFF from German
Hydraulic pipes	MANULI brand from German

Operating weight and working ranges
Operating weight		8400Kg
Length		7730 mm
Width		2500 mm
Height		2750 mm
Least radius of gyration		2270 mm
Height of cabin		1600 mm
Length of mouldboard		2320 mm
Width of mouldboard		400 mm
Working Range	Boom Length	3820 mm
	Bucket Arm Length	2330 mm
	Max.excavating range	6400 mm
	Max.excavating depth	4300 mm
	Max.excavating height	6500 mm
	Max.loading height	4500 mm
	Capacity of bucket	0.35-0.4 cbm
