Help CenterRotary Drum Washer for Potato Starch/ Cassava/modified/pea/making Machine
Related Products
-
Cassava Flour Processing MachineUS$ 10,000 - 8,000,000MOQ: 1 Set -
Cassava Flour Processing MachineUS$ 10,000 - 8,000,000MOQ: 1 Set
-
Cassava Flour Processing MachineUS$ 10,000 - 8,000,000MOQ: 1 Set
-
50ton/day Cassava Flour Processing MachineUS$ 10,000 - 8,000,000MOQ: 1 Set
-
Cassava Flour Production LineUS$ 10,000 - 5,000,000MOQ: 1 Unit
Company Information
Who we are?
We, Tidecom , is a European Technology professional company that manufacture and provide services to clients, which including turnkey project, engineering consulting, equipment supply, technical R&D, customer service. We are active in the fields like food, agricultural products, etc.
Our main business scope including:
Starch processing production line, including: potato, cassava, corn, wheat, sweet potato, pea;
Modified starch production line;
Starch sweeteners production line, including: glucose, maltose, fructose syrup;
Potato products production line, including: potato flake, granule, French fries, potato chips;
and other etc.
We have many successful project at home and abroad, Our company is responsible for the full turnkey projects such as project planning and design, equipment manufacturing, installation and commissioning of equipment and personnel training.
2.Drum washer information:
The rotary drum washer is mainly used in the production of starch, potato flour to wash the raw material.
The washer works according to the principle of countercurrent washing. The material flows from the inlet to the outlet along the twisted bar while the water in the rinse bath flows in the converse direction. Such movement can eliminate the sand and mud effectively.
3. Main technical parameters
|
Item
Type |
Rotary drum diameter mm |
Rotary drum length mm |
Capacity t/h |
Matched power kw |
Dimension mm |
TWA12 |
1200 |
2500 |
10 |
5.5 |
5800×2000×2000 |
TWA14 |
1400 |
3500 |
20 |
5.5 |
3800×2400×2000 |
TWA16 |
1600 |
4000 |
30~40 |
7.5~11 |
4300×2700×2200 |
TWA19 |
1900 |
4500 |
40~60 |
18.5~22 |
5300×2500×2300 |
Remark |
|
|
|
|
Products' Quality:
Quality Index |
First Grade |
Super Grade |
SGT Level |
Moisture % |
≤14.00 |
≤14.00 |
13.5-14.00 |
Ash % ≤ |
0.3 |
0.2 |
0.15 |
Whiteness 457nm,% ≥ |
90.0 |
92.0 |
96.0 |
Viscosity(Cassava Starch)Bu4%700cmg≥ |
- |
800 |
900 |
Detail procedures:
1. Raw material reception unit
2. Hydraulic transport unit
3. De-stoning and cleaning unit
4.Rasper
5. hydro-cyclone and de-sanding unit
6. Centrifugal extraction unit
7. Potato residue de-watering unit
8. Concentrating and refining unit
9. Vacuum de-watering unit
10. Flash drying unit
11. Screening and warehousing unit
12. Weighting and packing unit
Processing capacity:
10 tons per h potato
15 tons per h potato
20 tons per h potato
30 tons per h potato
60 tons per h potato
90 tons per h potato
4.Our main advantages:
Our drum washer is manufactured based on the european tecnology while the price is much lower than them. we have many sucessful project at home and abroad and win good reputation from our customers.
5.Our after sale service
If you want to learn more about our products or you have any questions, you can contact us anytime, we are willing to serve for you. Alice 8618756012409
