gsm modem rs232 price1.dual band or quad band
2.RS232 port or USB port
3.in stock
4.one year guartee
gsm modem rs232 price
1.CE Rohs FCC and others certification
2.Dual band or quad band
3.in stock
4.one year guarantee
5. USB or RS232 ports optinal
6.OEM or ODM also can be
General features Specifications Handsfree operation Special features
Following up the successful TC35i/MC35i Terminals, the new
generation of GPRS Terminals is available. Based on the
powerful MC55i wireless module platform the improved
Terminals offer additional functionality while remaining
compatible with its predecessors.
MC55i Terminal packs a Quad-Band GSM/GPRS baseband
with TCP/IP connectivity based on GPRS Class 10 data
transmission into a compact plug-and-play housing. The robust
housing includes a range of common interfaces as well as an
integrated SIM cardholder which make the new generation to an
all-in-one solution enabling voice, data, SMS and fax communication.
The new generation is available as Quad-Band with GPRS
Class 10 functionality (MC55iT) and as a Dual-Band variant with
GPRS Class 8 functionality (MC52iT). With an extended temperature
range, the reliable terminals can be used in a wide range of
M2M business fields such as metering, remote maintenance, traffic
systems, transportation and logistics, and security.
Like all Cinterion products, MC52iT / MC55iT come with full
type approval (FTA) and are certified according to automotive
e-mark as well as by the largest carriers worldwide.
GSM Quad-Band 850 / 900 / 1800 / 1900 MHz
(MC55iT)
GSM Dual-Band 900 / 1800 MHz (MC52iT)
3GPP Release 98
GPRS multi-slot Class 10/8
Compliant to GSM phase 2/2+
Output power:
Class 4 (2W) for GSM850
Class 4 (2W) for GSM900
Class 1 (1W) for GSM1800
Class 1 (1W) for GSM1900
SIM Application Toolkit
Control via AT commands (Hayes, 3GPP TS
27.007 and 27.005)
TCP / IP stack access via AT commands
Internet Services TCP server/ client, UDP, ICMP,
DNS, HTTP, FTP, SMTP, POP3
Supply voltage range: 8 - 30 V
Operating temperature: -30 °C to +75 °C
Dimensions: 65 x 74 x 33 mm
Weight: 110 g
WEEE
RoHS and EuP compliant
GPRS Class 10/8,
DL: max. 85.6 kbps
UL: max. 42.8 kbps (MC55iT)
UL: max. 21.4 kbps (MC52iT)
Mobile Station Class B
CSD data transmission up to 14.4 kbps, V.110,
non-transparent
USSD support
SMS text and PDU mode, cell broadcast
Fax group 3, Class 1 and Class 2
High quality voice support
FR, HR, EFR and AMR speech codec support
Integrated TTY modem Aluminum case Wavecom modem we can supply too power
Interfaces
Antenna connector FME (male)
Plug-in power supply connector
(6-pole Western jack)
Handset analog audio interface
(4-pole Western jack)
Mini-SIM card reader, 1.8 V and 3.0 V
V.24 / V.28 RS-232 interface
(D-sub 9-pole female socket)
Operating status LED
Serial interface modem driver for Microsoft®
Windows 7TM, Windows XPTM and
Windows VistaTM (MC55iT)
Firmware update via serial interface
Real time clock with alarm functionality
RIL driver Windows Mobile 6
Approvals
CE, R&TTE, GCF, FCC, PTCRB, IC, e-mark
Local approvals and network operator
certifications our factory
....
