Gsm Fixed Wireless Phone Terminal

Specifications

gsm fixed wireless phone terminal

Detailed offer Description

-Call termination & call origination

-Network Support:

  GSM 850 MHz 900 MHz 1800 MHz 1900 MHz

  CDMA 800MHz 1900MHz

-standard RJ-11 (FXS) to telephone or voip gateway & PABX

-4SIM automatic rotator (8 CHL 32 SIM cards) (optional)

- rotator by really clock (4 time oclock)

- rotator by dial times

- rotator by total talking minutes

- rotator by working hours

-IMEI changing function.(optional)

-Call Forwarding

-Caller ID

-Callback Function

-Provide accurate anti-polarity signal

-Support DTMF

-Support 2nd Stage Dialing

-Polarity reversal

-Barred telephone numbers can be set flexibly

-Locking wireless terminal, Locking SIM card, Locking districts and locking network

-Simple to install and easy to maintain

-High-quality voice

-Enhanced high gains external antenna

-Wide voltage range & Low power consumption

-Separate Power On/Off controller

FWT with 32 SIM cards User Manual

General description
-Simple to install and easy to maintain
-32 SIM cards auto switch. 4 SIM cards per channel.You can define each channel a working mode.It works in four modes:
Mode 1: work in different time of day.
Example: you can set first card to work from 12:00 am to 6:00 am,the second one to work from 6:00 am to 12:00pm,the third one to work from 12:00pm to 6:00pm.the fourth one work to from 6:00pm to 12:00am.
Mode 2: switch by the length of time on each SIM card on talking.
Example: you can set each card on talking for six hours.
the first card make calls for six hours,then switch to the second card,the second card make calls for six hours,then switch to the third card,the third card make calls for six hours,then switch to the fourth card,the fourth card make calls for six hours,then switch to the first card.
Mode 3:switch by calls each SIM card make
Example: you can set each card make ten calls.
the first card make ten calls,then switch to the second card,the second cards make ten calls,then switch to the third card,the third card make ten calls,then switch to the fourth card,the fourth card make ten calls,then switch to the first card.
Mode 4: switch by the working time.
Example: you can set first card to work 5 hours,the second card to work 1 hour,the third card to to work 3 hours,the fourth card to work 4 hours.
-Industrial module, work stable
-High-quality voice
-Provide accurate anti-polarity signal
-Support DTMF
-Call Forwarding
-Caller ID
-Support 2nd Stage Dialing
-Provide command sets from phone keypad
-Add prefixal code automatically:
-Callback Function:
-Barred telephone numbers can be set flexibly
-Locking wireless terminal, Locking SIM card, Locking districts and locking network
-Connection mode: RJ-11 phone sockets
-Enhanced high gains external antenna
-Wide voltage range & Low power consumption
-Support PC fax
-Power on/off indicator
-Signal strength indicator
-On/off hook indicator
-Working state indicator

Technical specification:
-GSM Module : GSM 850 MHz /900 MHz /1800 MHz /1900MHz.
-CDMA Module :CDMA 450 MHz/800 MHz/1900 MHz
-Width input voltage: AC 85 ~ 260V (47 ~ 63 Hz),
-Dialing frequency: 450Hz
-Transmitting power : <2 W
-Operation temperature:-10 ~ 60
-Operation humidity: 10% ~ 95%
-Atmosphere pressure:86 ~ 106 Kpa
-Environment noise:< 60dB
-Sensitivity < -105 dB
-Antenna Gain: 2.0 ± 0.5 db
-Hanging voltage: 45V
-Weight: 4.5kg

....
