2inch Thermal Printer Mechanism SMP650U

2inch Thermal Printer Mechanism SMP650U thumbnail-1
2inch Thermal Printer Mechanism SMP650U photo-1
US$ 15 - 15 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Feature:
Original
Brand Name:
bixolon
Model Number:
SMP650U
Contact Supplier Request Quote Chat Now
Shenzhen Shanhai Technology Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Feature Original
Brand Name bixolon
Model Number SMP650U
Place of Origin Seoul, South Korea

Specifications

1.Support SMP650U print head
2.Support graphic printing
3.Only support serial port
4.Apply area: bank, telecom, mobile,

2inch Thermal Printer mechanism SMP650U

1.Support SMP650U  print head
2.Support graphic printing
3.Only support serial port
4.Apply area: bank, telecom, mobile,

2inch Thermal Printer mechanism SMP650U

2inch Thermal Printer mechanism SMP650U2inch Thermal Printer mechanism SMP650U2inch Thermal Printer mechanism SMP650U2inch Thermal Printer mechanism SMP650U





Item Specifications
Printing method :Thermal Dot Line Printing
Resolution :8dots/mm
Dots per line :384dots
Printing width: 48mm
Maximum
Printing Speed: 70mm/s at 8.5V
Paper feed pitch : 0.0625mm
Head temperature detection :Via thermistor
Out of paper detection :Via photo interrupter
Operation voltage:
4.0~8.5 DCV (for head and motor drive)
3.0~5.5 DCV (for logic)
Current consumption
(at 7.2DCV, 64dots on)
For driving the Head : 2.8A max
For driving the Motor : 0.6A
Paper width 57.5 ± 0.5 mm
Paper feeding force 50gf or more
Paper holder force 80gf or more
Printer Life
(at 25° and rated energy)
Activation pulse resistance : 100million
Abrasion resistance : 50Km
Temperature range
Operating : 0°C to 50°C
Storage : -40°C to 80°C
(no condensation)
Humidity range
Operating : 10 to 90% RH
Storage :10 to 90% RH
(no condensation)
Impact resistance
Package SAMSUNG standard package
Height : 75Cm
Directions - 1 corner, 3edges and 6 surfaces
Recommended paper HANSOL PAPER 65GSM
Dimension (W×D×H) 68.8mm×32.5mm×15.5mm
Weight 40g
