Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product

Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product thumbnail-1
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product thumbnail-2
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product thumbnail-3
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product thumbnail-4
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product thumbnail-5
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product thumbnail-6
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product photo-1
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product photo-2
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product photo-3
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product photo-4
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product photo-5
Shengya Professional Manufactory QT5-20 Automatically Baking-free Concrete Clay Block/paver Making Machines China Product photo-6
US$ 13,438 - 33,423 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Paving Block Making Machine
Brick Raw Material:
Concrete
Contact Supplier Request Quote Chat Now
Shandong Shengya Machinery Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Paving Block Making Machine
Brick Raw Material Concrete
Processing Brick Molding Machine
Method Hydraulic Pressure
Automatic Other, Yes, yes
Capacity 20000 pcs for 200*100*60mm per day, 5500pcs/8h for 400*200*200mm
Place of Origin Shandong, China
Brand Name Shengya
Model Number QT5-20
Voltage 380V or more
Power 22 KW, 22KW
Dimension(L*W*H) 3650*2100*2720mm
Certification ISO9001/CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas
Product Description
Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product

(1)  Advanced hydraulic system and electro-hydraulic integration system is adopted,It is simple in operating and reliable in running



(2)  The material distributing system equipped with multirow of stirring forks ,can quickly and evenly discharge the material into the moulding box.



(3)  The integration of hydraulic system and vibrating make the brick shaping more quickly and the density of brick is strengthened .



(4)  The machine can also produce different sizes of blocks with different moulds.



Specifications:



main machine Power

22KW

Cycle

20S

Overall Size

3500X2000X2700mm

Carriage Size

1100X550X30mm

Electrical source

380V/50Hz

Total mass

5000kg

product quantity

400*200*200  5pcs/mould 5500pcs/8h

400*150*200  6pcs/mould 6700pcs/8h

200*100*60    20pcs/mold  20000pcs/8h



Contact : Cassie Sun              Mobile: +86-18816786169 (whatsapp/wechat)     Skype: cassiebbsun                Email: brick20 at





Video website: /watch?v=SJZt2uy3dp0&feature
                              /watch?v=yt2SyvDNxFM&feature
                              /watch?v=Sit6TIdzT9M&feature











Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product

                                                             Concrete mixer JDC350 specifications

 feeding capacity

        560L

 discharging capacity

        350L

 productivity

        17-21 M3/H

 speed of stiring shaft

        28R/MIN

 diesel engine  power

         15kw

 lifing hopper speed

         20M/min

 pump motor

         0.55

 Max. diameters of aggregates

         60/40mm

 stiring time

         30-35seconds

 standard height of dischaging

         2200mm

 dimension in transportation state

         2050x2550x2600MM

 weight

         3200KG

Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product



Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product

                                                                                 Conveyor belt( 7 meters)





Note: 1.The customer can choose which section he need,so the price is not fixed.











                                                                                   blocks & bricks samples as below:

Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product







Company Information

Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product



Warmly welcom to our factory for visiting!!

Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China productShengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product





Our Services

Quality Guarantee



Our professional engineer would text machine carefully before loading,so please rest assure.



Aftersale Services:

We have established eight oversea offices in Algeria,Cote d'Ivoire,Kenya,Nigeria,Ethiopia,Cameroon,DR Congo and Tanzania.We also have 3 after-service sites aborad :Angola,Sudan,the united Arab Emirates. So we can supply you better and in time service.

Selling is only the beginning of our service,

1,our good after-sale service would provide our customer with both the technology and the skills.

2, our overseas technicians would be there to help installation and teach the using method.

3, we could provide the manual brochure if needed.

Shengya professional manufactory QT5-20 automatically baking-free concrete clay block/paver making machines China product
