China manufacturer rice color sorter machine
Introduce of the rice color sorter
American top industrial 2048 CCD sensor for color sorter and Japanese tailor-made industrial camera for color sorter, identification and recognition have been improved obviously.
The fourth FPGA processor technology, improve processing speed and efficiency of mass data,increase throughput of color sorter.
New specialized ejector for color sorter, improve sorting accuracy and reduce carryover rate, air consumption reduce more than 20%.
Malfunction Self-Check, based on former ejector self-check, lamp self-check, pressure self-check and blower self-check, newly add camera check, ejector check, control board check and background board check, to reach machine malfunction self-check.
Brand new optical system design, effectively identify spot, light yellow, be the world big-league for sorting yellow with least carryover of white rice.
Keep double air passage system, ensure stable sorting under high percentage impurity.
Good at sorting various kinds of rice, wheats, millet, etc
Technical parameter of rice color sorter
Type |
A2 |
A3 |
A4 |
A5 |
A6 |
Channels |
128 |
192 |
256 |
320 |
384 |
Throughput (t/h) |
1.5-4 |
3-6 |
5-8 |
7-12 |
9-16 |
Sorting accuracy |
99.9% |
99.9% |
99.9% |
99.9% |
99.9% |
Optimal Carryover(bad:good) |
8:1 |
8:1 |
8:1 |
8:1 |
8:1 |
min resolution |
0.04 |
0.04 |
0.04 |
0.04 |
0.04 |
Voltage(V) |
~220v/50-60hz |
220v/50-60hz |
220v/50-60hz |
220v/50-60hz |
220v/50-60hz |
Power of main(kw) |
1.4 |
1.8 |
2.2 |
2.6 |
3.0 |
Air Pressure(Mpa) |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
Weight(kg) |
680 |
830 |
1000 |
1200 |
1400 |
Air Consumption(L/min) |
1.5 |
1.8 |
2.5 |
3.0 |
3.5 |
Dimensions(L×W×H)(mm) |
1082×1500×1920 |
1488×1500×1920 |
1794×1500×1920 |
2100×1500×1920 |
2406×1500×1920 |
Note:
Above data is measured on the basics of 2% impurity rate, please conside you rice capacity carefully.
Some function of rice color sorter
1.Reasonable channel assigns suitable for sorting grain with various size.
2.real Data transferring Bandwidth guarantees the data transferred rapidly, makes machine perform consistently and stably.
3.Latest Patent technology of image processing algorithm upgrades the accuracy, and accelerates the operation speed.
4.Seveal sorting modes meet various requirements.
5.Advanced system design with China Patent guarantees machine run stably for a long time.
6.Concise touch panel from China helps customer operate easily.
Sample reference:
