Wood pallet kibbler used in factory
- 30 Unit / Units per Month
- qingdao port china
- T/T Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | lankai |
Model Number: | LK-PSJ-1340 | Voltage: | 220/380V | Power(W): | 75kw |
Dimension(L*W*H): | 6500*2300*1900mm | Weight: | 3000KG | Certification: | ISO CE |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Wood pallet kibbler used in factory
Brief information:
Wood pallet crusher is a kind of spiral hammer roller crusher, which is special used to crush waste traditional wood pallet or compressed wood pallets. Also can be used to crush waste construction wood board.
Features of the machine:
1. High performance
2. Can crusher wood pallets with metal and nails.
3. Can crush wood pallet size less than:1340mm
4. Machine with metal remover, can remove metal in the wood chips
5. With dust collect equipments and low noise
6. The machine designed to reduce the material stay at the crushing chamber time which enlarge the life span of the machine.
Working principle:
The machine have two pinch roller, which help to feed the wood pallets or wood board in the chamber of the machine, this machine use the screen to control the crushed wood chips size. The machine can change screen to get different size of chips.The machine have the metal remover at the end which can remove the metals in the wood chips.
Wood pallet crusher structure:
The machine consist of: feeding conveyor , discharge conveyor, two pinch roller for feeding wood pallets, motor base, rotary shaft , and electrical controller box.
Technical parameter:
Model | LK-PSJ-1340 |
Main motor power | 75kw |
Capacity | 8-10ton/hour |
Feeding mouth size | 1340mm*180mm |
Max crushed wood pallet size | Width less than 1300mm Such as pallets:1200*1000mm 1200*800mm 1100*1100mm and 1300*1100mm |
Upper pinch roller power | 5.5kw |
Lower pinch roller power | 7.5kw |
Discharge conveyor power | 4kw |
Dust collect power | 4kw |
Feed speed | 0.8-1m/s |
Feeding rotary speed | 650r/min |
Crush rotary speed | 680r/min |
Final wood chip size | Less than 60mm |
Remark: Waste wood pallet crusher machine with dust remover, nail or metal remover which can remove nails in the waste wood pallets. Machine with electrical controller |
Main pictures:
Remark:
1. Delivery time: 15days after received your advanced payment.
2. Payment terms:40% Advanced payment by TT when you place the order
60% Balance by TT when send you scanned bill of lading.
3. Documents: The original documents will post to you immediately when we
received your balance by DHL or UPS or TNT express.
The original documents include:
- 1. Original bill of lading( three original and three copy)
- 2. Original commercial invoice
- 3. Original sales contract
- 4. Original packing list
- 4. Loading port: Qingdao seaport , China
- 5. The quotation valid time: valid for one month.
1:we pay more attention to the products quality,and we try our best to meet your request.
2:Our customers distribute all the world,mainly inclulde north east ,Africa,Europe,and so on.
3:Give us a chance is give yourself an opportunity.
We are sincerely to cooperate with all the friends.
If you have any questions please contact us !
