Specifications
Biomass pellets hot water boiler1.fuel:straw pellet,wood pellet
2.Integrated structure, Nice apperance.
3.Automaticlly
2013NEW and HOT Biomass pellets hot water boiler
Technical advantage:
1. The boiler is suitable for biomass pellet,auxiliary fuel:wood mass,coal pieces,etc.
2. Heating efficiency:91.15%.
3. Dust will be falled into inside ash bin automatcilly,nothing of the dust.
4. High temperature burning,low outflow smoke temperature.
5. Feeding one time for 5-10 hours working(according to boiler model).
6. Fine appearance,beautiful,bright colours.
7. PLC control system for adjustment of burning speed,flame.Reduce the noise.
9. Simple maintainance,don’t need to clean every day.Slagging/3days,clean ash/1-2 years.
10. Electric ignite,automatic device for saving the little fire,don’t need to ignite once again.
Description |
Unit |
CLHS0.018-W |
CLHS0.035-W |
CLHS0.06-W |
CLHS0.07-W |
CLHS0.08-W |
|
Rated power |
104 kcal |
1.5 |
3 |
5 |
6 |
7 |
|
Working pressure |
Mpa |
Atmospheric pressure
|
|||||
Hot water temperature |
°C |
85 |
|||||
Return water temperature |
°C |
60 |
|||||
Heating efficiency |
% |
89 |
|||||
Hot water outlet |
mm |
1" |
1" |
1.5" |
1.5" |
1.5" |
|
Water inlet |
mm |
1" |
1" |
1.5" |
1.5" |
1.5" |
|
Blowdown valve |
mm |
1" |
1" |
1.5" |
1.5" |
1.5" |
|
Electricity |
Induced draft fan |
W |
25 |
40 |
80 |
120 |
750 |
Fuel feeder |
W |
40 |
40 |
40 |
40 |
145 |
|
Gas flue |
mm |
¢140 |
¢140 |
¢140 |
¢140 |
¢140 |
|
Installing size( L×W×H) |
mm |
680×910×1100 |
790×960×1200 |
900×1080×1300 |
1000×1130×1300 |
1450×1230×1430 |
|
Loading size ( L×W×H) |
mm |
730×390×1150 |
840×440×1250 |
950×500×1350 |
1050×550×1350 |
1500×640×1480 |
|
Weight |
kg |
125 |
160 |
195 |
235 |
450 |
|
Fuel consumption |
kg/h |
2.85 |
5.71 |
8.52 |
11.26 |
13.3 |
|
Feeder consumption |
kg |
68 |
80 |
135 |
135 |
170 |
|
Fuel runing time |
h |
24 |
14 |
14 |
10 |
12 |
|
