Home > Industrial Equipment & Components > Boiler & Furnace > Boiler > 2013 New and Hot High Quality Biomass Pellets Hot Water Boiler

2013 New and Hot High Quality Biomass Pellets Hot Water Boiler

Name: 2013 New and Hot High Quality Biomass Pellets Hot Water Boiler
Brand: GOLE
SKU: 137507525

2013 New and Hot High Quality Biomass Pellets Hot Water Boiler thumbnail-1

2013 New and Hot High Quality Biomass Pellets Hot Water Boiler photo-1

US$ 1,000 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Natural Circulation

Usage:

Other, heating mode

Contact Supplier Request Quote Chat Now

Henan Province Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Natural Circulation

Usage Other, heating mode

Structure Fire Tube

Pressure Other, Atomospheric

Style Vertical

Fuel Other, wood pellet

Place of Origin Henan, China

Brand Name GOLE

Model Number GLK-Boiler hp-600

Output Hot Water

Certification CE

Specifications

2013 new and hot high quality biomass pellets hot water boiler
1.Thermal efficiency is 91.15%.
2.Outlet tempreture: 110-120 d

Product Series
wood pellet hot water boiler
Model GLK HP-600
Features:
*Thermal effeciency up to 91.15%
*Igniting only for one time,then keep tempreture atomatically;unnecessary to ignite again when restart.
*Smoking dust to be collected inside with cyclone automatically.
*High tempreture firing up to 800-900 centigrade, and low tempreture exhaust down to 110-120 centigrade.
*Working by 60% fired and 40%gasified; no coking occured
*It runs continuously 1-2 days by feeding fuels for one time.
*Non- smoke, non-coking and easy for ash cleaned.
*Feeding automatically. Low noisy and save cost.
*Nice appearance and easy maintenance.
*Fuel fired with wood pellet.
Biomass pellet features with problem:
Biomass pellets are very high in Alkali,Ash and Volatile Content.Especially for high Alkali when being in low
tempreture would be difficult to be in fully combustion,and then easy to corrode walls of boiler,also coking
occurred at the same time.
Our Professional Proposal:
1.Adopting process of 60% combustion and 40% gasfied to warrantee combusting room tempreture up to
800 centigrade above.
2.Pellet density needs to be above 1.1g/cm2. Acidity content to be added into raw materials to saturate
an Acidity and an Alkali,which would make calorific up to 4600-6000 kcal and more pro-environment too.

Item	Unit	CLHS-0.015	CLHS-0.028	CLHS-0.042	CLHS-0.06
Rated heating power	kw	15	28	42	60
Working pressure	Mpa	Normal atmosphere
Thermal effeciency	%	91.15
Power consumption:
Air system	kw	0.25	0.25	0.35	0.55
Ignitor system	kw	1.8	1.8	1.8	1.8
Chimney (diameter)	mm	114	114	114	114
Fuel consumption	kg/h	2.65	4.57	6.4	8.25
Silo Capacity	kg	120	120	120	120
Heating area	m2	80-120	120-200	200-280	280-400
Internal container heated	m2	1.76	1.98	2.33	2.66
Water yield	T/h	0.3	0.5	0.7	0.8
Water capacity	m3	0.15	0.2	0.3	0.33
Boiler weight	kg	184	241	261	285
Packing weight	kg	194	251	271	295
Packing dimension	mm	930X500X1100	980X520X1130	980X520X1130	1030X540X1150
Size for boiler room	mm	2430X2500X2100	2480X2520X2130	2480X2520X2130	2530X2540X2150
Continuous running	h	40	26	18	15

Our company is specialized for manufacture of biomass machinery and equipments. Our main products with sereies as Pellet Boiler, Pellet Stove, Pellet Burner, and machines for making pellets.

We are dedicated to develop and manufacture renewable energy machines and equipments.
We obtained great reputation not only in China ,but also around the European market and South of America. Grandlink Machine's first goal for company operation is to provide clients with hi-quality products, rapid delivery, and zealous service so that a great prestige around the world is of course earned .
