Mini CE standard Wall Hung Gas Boiler ( boilers with systemEU Technology
-Supply Heating & DHW
Mini CE standard Wall Hung Gas Boiler ( boilers with system)
Safety features:
-Triple overheat protection.
-Flameout protection.
-Reignition function.
-Defer ignition function.
-Anti-freezing function .
-Anti-lock function for pump.
-Overload protection for pump.
-Lightning strike protection.
-Overload protection for control system.
-Safety release function.
-Automatic circulation function of pump.
-Self-diagnostic function.
-Safety lock function.
-Automatic by-pass valve
Product characteristic:
-European Technology
-Provide both heating and shower water
-High efficiency and gas-saving
-Quietly working
-Intelligent and economical control system
-Easy operation with digital LCD screen
-Four section timer
-Remote controller optional
-Fashional appearance design
-High quality components with CE certificates
Technical parameters:
Model |
Unit |
JLG36-BF5 |
||
Rated Heat Input |
Kw |
36 |
||
Rated Output Power |
Kw |
32 |
||
Heat Efficiency |
% |
>88 |
||
Max. Power Input |
w |
145 |
||
Power Supply |
V/Hz |
220~230/50 |
||
N.W. |
Kg |
48 |
||
External Dimensions |
mm |
800X460X340 |
||
Index Of Protection |
IP |
IPX4 |
||
Insulation Grade |
|
I |
||
Gas Type |
LPG |
Rated Gas Pressure |
Pa |
2800 |
Gas Consumption |
Nm3/Kwh |
0.035 |
||
NG |
Rated Gas Pressure |
Pa |
2000 |
|
Gas Consumption |
Nm3/Kwh |
0.1 |
||
Central Heating |
Output Power Range |
Kw |
9.57~32.04 |
|
Water Temperature Range |
°C |
40~80 |
||
Reference Heating Square |
m2 |
180~280 |
||
Water Working Pressure Range |
Bar |
0.02~0.25 |
||
Heating Return Safety Valve Opening Water Pressure |
Bar |
3 |
||
Pump Lift |
M |
7 |
||
Expansion Vessle Capacity |
L |
10 |
||
DHW |
Output Power Range |
Kw |
9.57~32.04 |
|
DHW Temperature Set Range |
°C |
<65 |
||
Max. DHW Output Δt=25K |
Kg/min |
18 |
||
Operation Pressure DHW Range |
Bar |
0.03~0.7 |
||
Fittings |
Central Heating Fitting |
Inch |
G3/4 |
|
DHW Fitting |
Inch |
G1/2 |
||
Gas Fitting |
Inch |
G3/4 |
||
Coaxial Flue Pipe |
Straight |
mm |
Φ60/100 |
|
Elbow |
mm |
Φ60/100 |
||
Max. Permissible Flue Lengths |
Max. Horizontal Flue Length |
cm |
3 |
|
Max. Vertical Flue Length |
cm |
3 |
||
Flue Pipe Length Reduction For Elbows |
90° Elbow Φ60/100mm |
m |
1 |
|
45° Elbow Φ60/100mm |
m |
0.5 |
||
