Specifications
Steam Boiler:1.Compact structure
2. easy to install
3.Small footprint
4.Smal Investment
Product Introduction:
This series Steam boiler uses the general combustion techniques.The coal was feed by workers manually.After burning in the fire gate,the exhaust gas will pass trough the horizontal water tube,and the small carbon black in the exhaust gas will fall on the fire gate and re-burn.Then the exhaust gas will be released to the air though the chimney.
Name |
Nominal Capacity |
Working Pressure |
Saturated Steam |
Heating Area |
Design Grater |
Approx. Weight |
Model |
t/h |
Mpa |
°C |
m2 |
m2 |
mm |
LSG0.1-0.4 |
0.1 |
0.4 |
151 |
3.81 |
0.19 |
716×2505 |
LSG0.15-0.4 |
0.15 |
0.4 |
151 |
5.5 |
0.28 |
816×2750 |
LSG0.2-0.4 |
0.2 |
0.4 |
151 |
6.7 |
0.38 |
916×2750 |
LSG0.3-0.4 |
0.3 |
0.4 |
151 |
10.38 |
0.5 |
1020×3235 |
LSG0.4-0.4 |
0.4 |
0.4 |
151 |
13.38 |
0.63 |
1120×3510 |
LSG0.5-0.4 |
0.5 |
0.4 |
151 |
16.8 |
0.78 |
1220×3635 |
LSG0.6-0.4 |
0.6 |
0.4 |
151 |
20.8 |
0.95 |
1220×3635 |
LSG0.7-0.4 |
0.7 |
0.4 |
151 |
24.5 |
0.95 |
1320×3900 |
LSG0.8-0.4 |
0.8 |
0.4 |
151 |
28.5 |
1.13 |
1420×4320 |
LSG1-0.4 |
1 |
0.4 |
151 |
37.5 |
1.53 |
1624×4640 |
LSG0.3-0.7 |
0.3 |
0.7 |
170 |
10.38 |
0.5 |
1024×3235 |
LSG0.4-0.7 |
0.4 |
0.7 |
170 |
13.65 |
0.63 |
1124×3510 |
LSG0.5-0.7 |
0.5 |
0.7 |
170 |
16.8 |
0.78 |
1224×3350 |
LSG0.6-0.7 |
0.6 |
0.7 |
170 |
20.5 |
0.95 |
1324×3800 |
LSG0.7-0.7 |
0.7 |
0.7 |
170 |
24.5 |
0.95 |
1324×3900 |
LSG0.8-0.7 |
0.8 |
0.7 |
170 |
28.5 |
1.13 |
1424×4320 |
LSG1-0.7 |
1 |
0.7 |
170 |
37.5 |
1.53 |
1624×4640 |
