Quality!!! Ring Die Livestock Feed Making Equipment

Specifications

Ring Die Livestock Feed Making Equipment
1Hole diameter:1.5-12mm
2Length:0.5-8cm.
3For sheep,Cattle,chicken,Rabbit,pig.
4CE.

Quality!!! Ring Die Livestock Feed Making Equipment





1. Ring Die Livestock Feed Making Equipment:





a. It’s widely used for pellet of light substance,like wood chips,sawdust,straw,pasture,palm leaf and so on.



b. Adopt high-precision gear driven , advanced flexible coupling, for high productive efficiency .



c. Frequency converter control feeder flow, full stainless steel feeder, cover and chute .



d. Full stainless steel lengthened conditioner. Both paddle and shaft are made of stainless steel.





2. Main Data of Ring Die Livestock Feed Making Equipment:





type	Capacity(kg/h)	Power(kw)	Weight(kg)	Outline size(mm)	Particle specification(mm)	Forming rate(%)	Powdered rete(%)
FRLP-120	70-120	2.2	130	820*350*800	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-150	110-180	4	160	910*400*890	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-200	200-300	7.5	200	1000*430*950	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-230	300-400	11	290	1140*470*970	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-260	400-600	15	330	1220*500*1070	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-300	600-800	22	410	1220*600*1000	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-360	700-900	22	470	1220*600*1000	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%
FRLP-400	900-1000	30	550	1320*600*1050	2.5 , 3.2 , 4.0 , 5.0	>90%	<10%







3. Raw Material Rquired :









4. How to Work :



1> The Ring Die Livestock Feed Making Equipment is easy to operate, we will install the machine and test machine well before delivery, once user connect it with electric power, and the raw material is delivered into the  Ring Die Livestock Feed Making Equipment through a conveyor and then conveyed into a rotating ring die by a feeder.



2> Finely pulverized material will be pressed into ring die through two rotating press rollers. The resulting pressure compresses the material and extrudes it through the holes in the die. The Ring Die Livestock Feed Making Equipment;out directly.





The materials can be corn, maize, wheat bran, bone powder, fish powder, with nutrition material, and vitamin etc.

the animal feed manure can be used as raw material for Ring Die Livestock Feed Making Equipment .





5. More of Ring Die Livestock Feed Making Equipment :
