Specifications
flat die complete poultry feed mill1Hole diameter:1.5-12mm
2Length:0.5-8cm
3For sheep,Cattle,chicken,pig,Rabbit etc
4CE.ISO
High output flat die complete poultry feed mill
1.flat die complete poultry feed mill :
a. It’s widely used for pellet of light substance,like wood chips,sawdust,straw,pasture,palm leaf and so on.
b. Adopt high-precision gear driven , advanced flexible coupling, for high productive efficiency .
c. Frequency converter control feeder flow, full stainless steel feeder, cover and chute .
d. Full stainless steel lengthened conditioner. Both paddle and shaft are made of stainless steel.
2. Main Data of flat die complete poultry feed mill :
type | Capacity(kg/h) | Power(kw) | Weight(kg) | Outline size(mm) | Particle specification(mm) | Forming rate(%) | Powdered rete(%) |
FRLP-120 | 70-120 | 2.2 | 130 | 820*350*800 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-150 | 110-180 | 4 | 160 | 910*400*890 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-200 | 200-300 | 7.5 | 200 | 1000*430*950 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-230 | 300-400 | 11 | 290 | 1140*470*970 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-260 | 400-600 | 15 | 330 | 1220*500*1070 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-300 | 600-800 | 22 | 410 | 1220*600*1000 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-360 | 700-900 | 22 | 470 | 1220*600*1000 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
FRLP-400 | 900-1000 | 30 | 550 | 1320*600*1050 | 2.5 , 3.2 , 4.0 , 5.0 | >90% | <10% |
3. Raw Material Rquired :
The materials can be corn, maize, wheat bran, bone powder, fish powder, with nutrition material, and vitamin etc.
the animal feed manure can be used as raw material for flat die complete poultry feed mill .
4. How to Work :
1> The flat die complete poultry feed mill is easy to operate, we will install the machine and test machine well before delivery, once user connect it with electric power, and the raw material is delivered into the flat die complete poultry feed mill through a conveyor and then conveyed into a rotating ring die by a feeder.
2> Finely pulverized material will be pressed into ring die through two rotating press rollers. The resulting pressure compresses the material and extrudes it through the holes in the die. The flat die complete poultry feed mill;out directly.
5. More of flat die complete poultry feed mill :
Look forward to your early contact:
