- Application
HMC-20B grinder is suitable for grinding of Chinese herbal medicine compound and raw materials in industries such as food, fodder and chemistry.
2. Working principle
The electrical motor drives the main shaft to rotate at a high speed and spin off the material into the grinder, The material is ground between the moving plate and the fixed plate by striking, shearing and grinding, The ground material is carried by the air flow through the screen to the collecting bag. The size of the particle can beadjusted by changing the screen with different screen holes.
3. Structural characters
The machine is featured with simplicity,compactness,smooth running and high grinding efficiency. The internal structure is convenient for cleaning, repair and maintenance; and provides such advantages as low noises, less power consumption, compactness, nice appearance, etc in addition, the outer surface of the grinder, housing and the part which contacts the material are all made of stainless steel, allowing the production of the pharmaceuticals, food and chemicals to satisfy the national standard and meet the requirements of GMP.
4. Main technical specifications
(1). Working chamber: 200mm
(2). RPM of main shaft:5680r/min
(3). Working current:<4.5A
(4). Output capacity:50-100kg/h
(5). Degree of grinding:20-120 mesh
(6). Power :4KW
(7). Net weight:75kg
(8). Overall dimension:600*600*1200
