Specifications
Drive Rollerhigh load, strong.material:carbon steel or stainless stee
surface treatment:zine plated,blackened or rubber coate
Drive Roller Jolinpack
Type |
Dia.&Thickness (mm) |
Shaft (mm) |
Roller length (mm) |
Load (kg) |
Tube material |
Surface treatment |
CR-01(02)-Φ38 |
Φ38*1.5 |
Φ10/12 |
150-800 |
25-60 |
Carbon steel Stainless steel |
Zinc plated Blacken Rubber coated plastic-covered |
CR-01(02)-Φ50 |
Φ50*1.5 |
Φ12 |
150-1200 |
40-100 |
||
CR-01(02)-Φ60 |
Φ60*2.0/2.5 |
Φ12/15 |
150-1200 |
40-100 |
Type |
Dia.&Thickness (mm) |
Shaft (mm) |
Roller length (mm) |
Sprocket wheel |
Tube material |
Surface treatment |
LR-01-Φ38 |
Φ38*1.5 |
Φ12 |
100-1200 |
06B11/13 |
Carbon steel Stainless steel Aluminum alloy |
Zinc plated Blacken Rubber coated plastic-covered |
LR-01-Φ50 |
Φ50*1.5/2.0 |
Φ12 |
100-1500 |
08B11/14 |
||
LR-01-Φ57 |
Φ57*1.5/2.0 |
Φ12 |
100-1500 |
08B11/14 |
||
LR-01-Φ60 |
Φ60*2.0/3.0 |
Φ12/15 |
100-1500 |
08B11/14 |
||
LR-01-Φ76 |
Φ76*3.0 |
Φ20 |
100-2000 |
10A13 |
||
LR-01-Φ89 |
Φ89*4.5 |
Φ20 |
100-2000 |
10A13 |
Type |
Dia.&Thickness (mm) |
Shaft (mm) |
Roller length (mm) |
Sprocket wheel |
Tube material |
Surface treatment |
LR-02-Φ50 |
Φ50*1.5/2.0 |
Φ12 |
100-1500 |
08B11/14 |
Carbon steel Stainless steel Aluminum alloy |
Zinc plated Blacken Rubber coated plastic-covered |
LR-02-Φ60 |
Φ60*2.0/3.0 |
Φ12 |
100-1500 |
08B11/14 |
||
LR-02-Φ76 |
Φ76*3.0 |
Φ20 |
100-2000 |
10A13/14 |
Type |
Roller Dia. (mm) |
Taper |
Shaft Dia (mm) |
Roller length (mm) |
Sprocket wheel |
Load (kg) |
Tube material |
Surface treatment |
LZR-Φ42(Φ50) |
Φ42 Φ50 |
3.60 |
Φ12 |
200-800 |
08B11/14T |
40-110 |
Carbon steel Stainless steel |
Zinc plated Blacken Rubber coated |
LZR-Φ56 |
Φ56 |
3.60 |
Φ12 |
200-1200 |
08B11/14T |
45-130 |
Type |
Dia.&Thickness (mm) |
Shaft Dia (mm) |
Sprocket wheel |
Roller length (mm) |
Load (kg) |
Tube material |
Surface treatment |
LJR-01-Φ50 |
Φ50*1.5 |
Φ12 |
08B/11T |
100-800 |
35-85 |
Carbon steel Stainless steel |
Zinc plated Blacken Rubber coated |
LJR-01-Φ60 |
Φ60*2.0 |
Φ12 |
08B/11T |
100-1200 |
40-100 |
Type |
Dia.&Thickness (mm) |
Shaft Dia (mm) |
Sprocket wheel |
Roller length (mm) |
Load (kg) |
Tube material |
Surface treatment |
LJR-02-Φ50 |
Φ50*1.5 |
Φ12 |
08B/9-14T |
100-800 |
40-125 |
Carbon steel Stainless steel |
Zinc plated Blacken Rubber coated |
LJR-02-Φ60 |
Φ60*2.0/1.5 |
Φ12/15 |
08B/9-14T |
100-1200 |
80-440 |
||
LJR-02-Φ76 |
Φ76*3.0 |
Φ20 |
08B/9-14T |
200-1200 |
250-570 |
||
LJR-02-Φ89 |
Φ89*3.5 |
Φ20 |
08B/9-14T |
200-1200 |
280-710 |
Type |
Rating current |
Shaft Dia (mm) |
Sprocket wheel |
Roller length (mm) |
Load (kg) |
Length:300 400 500 600 700 800 | |||||
DRB6012 |
0.12A |
0.66A |
3-21M/min |
3 phase 220-380V |
30W 50HZ |
DRA7620 |
0.35A |
1.25A |
5-30M/min |
3 phase 220-380V |
60W 50HZ |
