Help CenterStrech Wrapping Machine
Related Products
Main technical parameter:
Stretch Wrapping Machine | |
Standard Specification | |
Type |
JT-2000A |
Pallet size |
(L)1400*(W)1200mm |
Turntable diameter: |
2,000mm |
Turntable height |
600mm |
Max. wrapping height |
1800mm(including wooden palte) |
Max. wrapping weight |
over 2,000kgf |
Turntable speed |
2-14 circles/min (adjustable) |
Film frame elevation speed |
1-3m/min |
Machine dimension |
(L)3,000mm (W)2,000mm (H)3,450mm |
Machine weight |
1200kgs |
Turntable conveyor valid width |
1300 mm |
Pre-stretch tension rate |
1:2.5(make the usage rate up to 2.5 times to original) |
Pneumatic |
6-7kg/cm2 |
Powe |
380V,50Hz |
Film width |
500mm,thickness 12-35μ |
Film diameter |
inner dia 76mm,max outer dia 350mm |
Motor |
natianl famous brand |
PLC |
Japan Mitsubishi |
Contactor and switch |
France Schneider |
Frequency |
Other brand |
Photosensor |
Japan Omron or Yamatake |
|
Features: Packing circles of superstratum and under layer are separately setting by PLC shortcut button. Mid-strengthen-function design, any parts can be strengthened Double deck packing pattern, free design the film overlapping degree upon the different packing requirements. Pre-stretch motor film frame design, gear box system and transducer control the tension together, greatly save the packing material, make better packing effect. Auto photoelectricity measure height & turn table location. Set drive roller conveyor on turn table. Automatic clumping and cutting system. Turntable speed & film frame vertical speed are controlled by transducer, stepless speed changing. Control mode: PLC + Transducer + Touch screen+ standard control button + signal switch, automatic /manual control two control patterns. Lucia Ma Customer manager Dalian Jialin Machine Manufacture Co.,Ltd. Add:NO.138 Guofang road, Jinzhou district,Dalian, China Tel:0411-66366707, 0411-87673797-8010 Fax:0411-87683017 Email:mxd@dljialin.com Website: (CHN) (ENG) /jp(JPA) Feedback:mxd@dljialin.com Products Range: 1.Full set of automatic conveyor and assembly line in factory, conveyor for food or medical, electrition assemble line, seafood processing line. Belt/Roller/Chain conveyor, vertical conveyor, Cold-chain warehouse system. 2.Full set of automatic assembly and packing line, food or medical production and packing line, beer , drinking, soft bag, carton packing line. Plastic or glass bottle pack line. Robot Palletizer for paper carton or bag and packing line. Carton erector, packer, sealer, robot palletizer and etc
| |
