Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Processing Machinery Parts > on Line Strech Wrapping Machine

on Line Strech Wrapping Machine

Name: on Line Strech Wrapping Machine
Brand: JIALIN
SKU: 137403771
Availability: InStock

on Line Strech Wrapping Machine thumbnail-1

US$ 1 - 99,999 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Liaoning, China

Brand Name:

JIALIN

Model Number:

JT-2000A

Contact Supplier Request Quote Chat Now

Dalian Jialin Machine Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Liaoning, China

Brand Name JIALIN

Model Number JT-2000A

Condition New

After-sales Service Provided Engineers available to service machinery overseas

on line strech wrapping machine

Stretch Wrapping Machine
Standard Specification
Type	JT-2000A
Pallet size	(L)1400*(W)1200mm
Turntable diameter:	2,000mm
Turntable height	600mm
Max. wrapping height	1800mm(including wooden palte)
Max. wrapping weight	over 2,000kgf
Turntable speed	2-14 circles/min (adjustable)
Film frame elevation speed	1-3m/min
Machine dimension	(L)3,000mm (W)2,000mm (H)3,450mm
Machine weight	1200kgs
Turntable conveyor valid width	1300 mm
Pre-stretch tension rate	1:2.5(make the usage rate up to 2.5 times to original)
Pneumatic	6-7kg/cm²
Power	380V,50Hz
Film width	500mm,thickness 12-35μ
Film diameter	inner dia 76mm,max outer dia 350mm
Motor	natianl famous brand
PLC	Japan Mitsubishi
Contactor and switch	France Schneider
Frequency	Other brand
Photosensor	Japan Omron or Yamatake
Features: Packing circles of superstratum and under layer are separately setting by PLC shortcut button. Mid-strengthen-function design, any parts can be strengthened Double deck packing pattern, free design the film overlapping degree upon the different packing requirements. Pre-stretch motor film frame design, gear box system and transducer control the tension together, greatly save the packing material, make better packing effect. Auto photoelectricity measure height & turn table location. Set drive roller conveyor on turn table. Automatic clumping and cutting system. Turntable speed & film frame vertical speed are controlled by transducer, stepless speed changing. Control mode: PLC + Transducer + Touch screen+ standard control button + signal switch, automatic /manual control two control patterns.
