High Speed Carton Erector

Standard Specification

Type

JTK-09

Carton size

(L)200-450(W)150-400(H)100-350mm

Table height

min. 650 mm

Working speed

600-720ctns/hour

Machine size

(L) 2000mm, (W) 1900mm, (H) 1200mm

Power

220/380V, single phase, 50/60Hz

Tape width

48mm, 60mm, 75mm (choose one)

Pneumatic

5-6kg/cm² 150 L/min

Machine net weight

approx. 350kgs

Motor

Taiwan Brand, CE certified.

Pneumatic element

Taiwan AirTAC

PLC

Japan Mitsubishi

Contactor and switch

France Schneider

Photo sensor

Japan Omron

Features:

1. Perfect working on forming and sealing for soft cartons;

2. Vertical storage is adopted to for storing carton blanks, for which carton blanks can be added

    at any time without stopping the machine.

3. Auto process of grabbing, forming and bottom sealing;

4. Adjustment for cartons only needs 1-1.5 min , is the fastest inland for now;

5.The erector is man-machine interface control (Taiwan brand 5.7 inch color touch screen),

   auto updating, moving process and alarming.

6.Touch screen could help to find the fault and solve problem at the first time.
