Factory direct Automatic 6 lanes shampoo filling and packing machine
- 20 Set / Sets per Month
- Shanghai or any port in china
- T/T
- Inside and outside bag packaging line Healthy teatriangle packaging linkage line
- Pharmaceuticals industrypackaging assembly line Packaging production line
- China teatriangle packaging linkage line Green teainternal and external package linkage line
- Packing and palletizing linkage line Beverage industrybox and palletizing production line
- Pharmaceuticals industrypackaging linkage line Packaging production line
- Box code stack production line Beverage industrybox and palletizing assembly line
Product Details
Application: | Beverage, Chemical, Commodity, Food, Medical | Packaging Type: | Bags | Packaging Material: | Plastic |
Automatic Grade: | Automatic | Driven Type: | Electric | Voltage: | 220V/380V |
Power: | 3KW | Place of Origin: | Shanghai, China | Brand Name: | Shouda |
Model Number: | SD-DBJ6 | Dimension(L*W*H): | L2330*W1230*H2000mm | Weight: | 600kg |
Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Factory direct Automatic 6 lanes shampoo filling and packing machine
Feature:
- PLC Control, English and large touch screen, Frequency step less bag length adjustable.
- Easy operation, smooth performance, low noise, compact construction, convenient to maintenance, long life in use, small floor space in high packing speed and efficiency.
- The case of machine is made of stainless steel S/S304.
- Photoelectric tracking system for precise bag length and position of film.
- Length and width of bag is easy to adjust on the interface without changing mould.
- Digital temperature controller for vertical and horizontal sealing, intuitive and accurate.
- Made according to the width of the bag, no wasting packing .
- Parameter:
Rows
6 Rows
Article
liquid
Model
SD-DBJ6
Measuring Range
5-60ml/bag
Film width (max)
480mm
Size of bag
L40-400mm W30-60mm
Capacity
Max 270 bags/min
Control style
PLC control system + English interface
Case of machine
Stainless steel
Material feeder
pneumatic
Air consumption
0.4m³/min 0.4-0.7Mpa
Power
3000W
Power supply
Alternative (Please tell me the voltage you will use.)
Weight
N.W650kg;G .W680kg
Dimensions (mm)
L2330*W1230*H2000
Sealing style
4 sides sealing
1.When we get your inquiry, we’ll recommend you the exact suitable machine for you.
2.We’ll reply to your email within 12 hours
3.We provide responsible and complete after-sales service.
4.Technical support, we can offer video for debugging
3.By the way,We can purchase packging film for you, according to your needs and requirements.
About warranty:
1.one year warranty,within warranty period ,we will provide free parts for replacement,if any problem belongs to us (delivery cost paid by customer)
2.if there are any malfunction for the machine.we will try our best to solve the problem within 24 hours
3.We can provide installation and maintenance service at your place if you need.
1. Can your machine meet our needs well?
After receiving your inquiry, we will confirm your packing material, packing volume, bag size, packing speed and precision, and any other requirments, and then give you the proposal according to your specific requirments. Every machine is customized to meet your needs well.
2. Are you factory or trading company?
We are the factory manufacture and sell various packing euipments. We have engaged in the packing production over 10 years.
3. What's your payment way?
T/T by our bank account directly, or by alibaba trade assurance service, or by LC.
4. How can we make sure about the machine quality after we put the order?
Before delivery, we will send you the pictures and videos for you to check the quality, and also you can quality checking in our factory.
5. We are afraid you won't send us the machine after we send you the money?
Please note our above business license and certificate. And if you don't trust us, then we can use alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
6. Why we should choose your company?
We are professtional in packing machines over 10 years, and we provide better after-sales service. You guarantee no risk for our deal.
