360-Degree Bird View Car Camera Recorder

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Certification:

Place of Origin:

Guangdong, China

Brand Name:

OEM

Xian Far East Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Certification CE

Place of Origin Guangdong, China

Brand Name OEM

Model Number BDV360-R

Specifications

1. 25 years' experience in export
2. CE, FCC, ISO9001:2000
3. Credible quality
4. Delivery in time

Birdview box				Record Function
CPU:NEXPERIA VICARO2 (from PHILIPS)				H.264 high-definition compression format
RAM:256MByte DDR2				Video quality: D1(720x480) P20fps/s
FLASH:32MByte				Micro SD card:8G (7 hours record)
Video output:CVBS				A file duration is 10 minutes, size is 150M byter
Video System:NTSC/PAL				ACC ON automatic recording
IR remote control
Working Voltage:DC8V-32V(12V in car)
Working temperature:-40°C~80°C

HIGH TECHNOLOGY SOLUTION
The technology comes from NXP Semiconductor Company belonged to PHILIPS.
360º BIRD-VIEW
This system adopts seamless conjoin display technology which can integrate four pictures into 360 degree birdview picture around the car and real-time picture
output to the monitor without blind area.
4CH HD CAMERAS
This system use four cameras which are high definition, night vision and big angle and the system can adjust the pictures luminance automatically.
CYCLE RECORDING
The system can extend to recording. It can use TF card max to 32G. Four channel or one channel real-time recording is option.
3 WAYS FOR SYSTEM WARKING UP
1.Turn on the system by back up trigger
2.Turn on the system remote control
3.Turn on the system by double press down caution light.
