HWZ -Microwave Vacuum Drying and Sterilizing Machine
Microwave Vacuum Equipment Description:
This product can be applied for drying solid heat sensitive herbal medicine (liquid, semi liqud, solid) at low temperature. Materials can also be sterilized during this process.
Technical features:
Heat-sensitive medicine can be dehydrated and hereby dryed and concentrated quickly. The drying temperature can be controlled lower than 40°C.
Infrated mesurment of temperature, digital timing, adjustable output power
Inteligent control, simple operation and equal heating. More than 50% of electricity can be saved comparing with conventional equipment without microwave and vacuum functions.
1KW working power is able to dehydrate about 0.6kg water in one hour.
Technical parameter
Frequency: 2450±50MHz
Input power: ≤60KVA
Microwave output power: 6-30kW(adjustable)
Temperature for Microwave drying and sterilizing: 20-60°C
Application:
Liquid herbal medicine; herbal extract;semi liquid or solid heat sensitive material
ItemUnit |
HWZ-BC |
HWZ-BC |
HWZ-BC |
HWZ-BC |
HWZ-25B/30B |
||||
Microwave Power |
5 |
10 |
15 |
20 |
25-30 |
||||
Microwave Frequency |
2450 |
2450 |
2450 |
2450 |
2450 |
||||
Supply Voltage |
380±10% |
380±10% |
380±10% |
380±10% |
380±10% |
||||
Area ofspreading materials |
0.75 |
0.75 |
2.25 |
2.25 |
3.4 |
||||
Sterilization Capability |
10 — 20 |
||||||||
Dehydration Spssd kg/ kw .h |
0.8—0.2 |
||||||||
Dehydration Temperature C' |
300—100 |
||||||||
External dimension (L*W*H) |
1290*1190*1880 |
1580*1190*1880 |
1780*20000*2140 |
1780*2000*2140 |
1880*2400*2420 |
||||
