Biomass Drum Dryer

Name: Biomass Drum Dryer
Brand: changgan
SKU: 137284641
Availability: InStock

US$ 20,000 - 200,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Drum Drying Equipment

Place of Origin:

Jiangsu, China

Contact Supplier Request Quote Chat Now

Changzhou No. 2 Drying Equipment Factory Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Drum Drying Equipment

Place of Origin Jiangsu, China

Brand Name changgan

Model Number HZG

Certification CE

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

HZG rotray drum dryer

wood chips dryer Description
After the damp raw material is put into the drier from on end, it is turned over through strring-up rake inside the cylinder and distributed uniform in the drier and contacted with countercurrent hot air fully. It speeds up heat and mass conducting of dry. During the oeriod of dry, raw material is effcted by stirring-up rake with gradient and hot air, it can be moved and passed through the dry region and to star valve and then discharge the finished product.

rotary drier Technical parameters

item(m)	priductive capacity(t/h)	revolution(r/min)	motor power(Kw)	install angle(^.)	Temp.of final
Φ1.0×5.0	0.5-1.2	0.6-6	4	3-5	≤1.5%
Φ1.2×6-10	1.5-3	0.6-6	5.5	3-5	≤1.5%
Φ1.5×12-18	3-5.5	0.6-6	15	3-5	≤1.5%
Φ1.8×12-18	5-6.5	0.6-6	18.5	3-5	≤1.5%
Φ2.2×12-22	7-12	0.6-6	22	3-5	≤1.5%
Φ2.4×15-20	9-15	0.6-6	30	3-5	≤1.5%
Φ3.0×25	16	0.6-6	55	3-5	≤1.5%

model	heat direct and sequence		heat direct and retrograde		compound heating
type of material	mineral	HP		ammonium sulphate	phosphorus fertilizer	coal
capacity kg/h	1000	-66	15000	20000	12000	5000
primary moisture %	30	13	6	1.5	5	6.5
final moisture %	15	0.3	1	0.1	0.1	0.1
average dim. mm	6.5	0.05	4.7	0.5-0.7	0.5	5
thickness of material mm	770	800	1890	1100	1500	750
capacity of hot air kg/h	39000	5400	10750	9800	6500	16000
temp. of air in	600	165	500	180	650	570
temp. of material out		42	100	70	80	75
heating style	gas	steam electric+heating	heavy oil	coal fuel furnace	heavy oil	heavy oil
ratio of feed		6.3	7	7.5	7.8	18
rotation speed rpm	4	4	3.5	3	4	2
angel ^.	0.04	0.005	0.03	0.05	0.05	0.043
quatity of oar	12	24	12	22	8 16	6 12
dim. of drier m	2.0	1.5	2	2.3	2 0.84	24 0.95
length of drier m	20	12	17	15	10	16
driving power kw	22	7.5	15	11	11	15

Company introduction:

Changzhou No.2 Drying Equipment Factory Co.,Ltd is an old drying enterprise which has 23 years drying history. We have got several patents in different dryers. We have much experience in different drying area. Now it holds more than 100 sets of equipment. The company has more than 100 staff and workers, including 15 engineers, with annual value of production more than thirty-eight million RMB.We attach importance to advanced technology, and have cooperated positively with universities and colleges to develop new products by using new technics. We have continuously developed several key and high-tech products with advanced technology both from domestic and abroad.During the past ten continuous years, the company has been appraised as enterprise with high reputation on contract and credit.Bases on the principle of factualism, innovation and mutual benefit, the enterprise is looking forward to creating resplendence with personages from all circles together.

Certificate and Letters Patent:

Service:

The Warranty Period of the dryer machine shall be 12 months from the date of completion of the installation and commissioning of the Contract.

We will provide some spare parts for free together with dryer before shipping, paid service will be provided for the long term, and we can provide components at competitive price.
