Zhengzhou shuliy machinery co.,ltd
catalytic cracking-condensing waste tyre machine
Reactor
1. The gear is seperated from reactor, instead of welding on reactor. So it will not be destroyed by heating.
2. The reactor is supported in a centre line by rollers. It will remain stable while running.
3. Auto-welding, both inside and outside.
4. Made by special boiler plate Q345R. Security and long service life.
5. Made by rock wool insulation board. Save fuel and ensure heating effect.
Auto-feeder
1. 50 ton hydraulic pressure help feeding more raw materials.
2. The diameter is 1.4m. It can feed all kinds of raw materials, including plastic, packages of plastic, truck tire, car tire, or tire pieces after cutting.
3. Save labor, save time.
4. After finishing production it can feed raw material instead of waiting the reactor to be cooled.
Catalyst chamber
1. Improve the oil yield and oil quality.
2. Impurity of oil gas will be collected here.
3. Reduce the speed of oil gas so that it will be better cooled.
Oil-water separator
1. Water from raw material will be separated here
2. Water sealing design prevent tempering. Ensure saftety.
3. Heavy oil will be collected here.
Condenser
1. The oil gas is cooled separately by 57 pipes inside the condenser. Improve the oil yield by better cooling effect.
2. Series connection for condenser makes the cooling process longer.
3. Light oil will be collected here.
Vacuum device
1. Keep reactor running under normal pressure.
2. Ensure safety.
Anti-back fire device
1. Little residual gas can not be cooled. It will recycle these gas to furnace burning to heat the reactor.
2. Water sealing disign will prevent tempering. Ensure safety.
Dust removal device
1. Dispose of flue gas caused by heating reactor using coal, wood, oil or natual gas.
2. Environment protection.
parameters
External dimension of main machine(Diameter*Length) |
2600*6000mm(1set) |
||
Raw material |
Waste tire , Waste rubber |
||
Oil yield/day |
Waste Tire |
Big tires |
45%-50% |
Car tires |
40% |
||
Bicycles and motorcycles tires |
30% |
||
Structural Form |
Horizontal |
||
Capacity/day |
1-2 batch/day |
||
Equipment Type |
Universal Equipment |
||
Operating pressure |
Ordinary pressure |
||
Power |
Coal ,fuel gas , fuel oil , wood |
||
Mode of cooling |
Water-cooling |
||
Working form |
Uncontinuous |
||
|
24 hour disposal amount (As shown in the quotation list) |
8 tons raw material |
||
24 hour oil yield |
Depends on the raw material |
||
Rotate speed of main equipment |
0.4 turn/min |
||
Power in total |
10.5 kw/hour |
||
Heating mode |
Direct heating |
||
detailed picture
If you are interested in our machine,welcome contact with me.
