California Bearing Ratio CBR Test Apparatus for Soil Testing

California Bearing Ratio CBR Test Apparatus for Soil Testing thumbnail-1
California Bearing Ratio CBR Test Apparatus for Soil Testing thumbnail-2
California Bearing Ratio CBR Test Apparatus for Soil Testing photo-1
California Bearing Ratio CBR Test Apparatus for Soil Testing photo-2
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Delhi, India
Brand Name:
LABAIDS
Model Number:
SOIL 104
Contact Supplier Request Quote Chat Now
Divine International
Payment & Shipping
Payment Methods:
Port of Shipment:
Delhi
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Delhi, India
Brand Name LABAIDS
Model Number SOIL 104

LABAIDS Motorised California Bearing Ratio (CBR) Test set equipment consists one each of the following:



<![iLoad Frame, Motorised, Capacity 5000kg, (Single Speed 1.25mm/min OR Three Speed 1.25, 1.5, 2.5mm/min).



<![iCBR Mould 150mm internal dia x 175mm high



<![iPerforated base plate and extension collar 50mm high.



<![iPenetration piston, face dia 50mm with adjustable bracket for penetration dial gauge.



<![iCircular metal space disc, 148mm dia x 47. 7mm high, with detachable handle.



<![iAnnular metal weight, 2. 5 kg. , 147mm dia with 53mm dia central hole.



<![iSlotted metal weight, 2. 5 kg. , 147 mm dia with 53 dia slot.



<![iPerforated plate made of gun-metal / brass 148mm dia with adjustable stem and lock nut

A metal tripod for dial gauge.

Cutting collar



<![iRammer 2. 6 kg weight with drop of 310mm.



<![iRammer 4. 89 kg weight with drop of 450mm.



<![iProving Ring 50KN with dial gauge 0.002mm,  5mm



Dial gauge 0.01mm, 25mm
