Energy saving and environmental biodiesel oil machine
Big biodiesel oil making machine
Biodiesel oil processor and machinery biodiesel machine
High quality of biodiesel equipment , oil mill machinery
Biodiesel is used for chemical industry field, it makes bio-oil into biodiesel. Bio-oil can be plant oil ,animal oil or high acid oil waste oil.
The set of biodiesel equipment contains the international advanced pre-processing section,esterification process and distillation
process,and it meets the European Union Standards.We have obtained patent,and patent No. is ZL200920089138.8.
The production steps are as follows:
1.Preprocessing section of bio-oil: when heated to 65~70°c, bio-oil is leached to impurities.
2.Drying section:bio-oil without impurities is dehydrated and dried.
3.First esterification reaction:adding bio-oil dehydrated to methanol including 3% sulfuric acid,first esterification reaction starts,and it will take 1.5~2.5 hours.
4.Second esterification reaction:this esterification reaction will take 9~12 hours.
5.Vacuum drying section: Second esterification reactants are dried with vacuum,removing moisture,reducing water content below 3%.
6.Distillation section: with vacuum state,section esterification reactants after vacuum drying section are heated to 220°c,biodiesel forms by steaming.Then cooling biodiesel to be liquid ,the liquid biodiesel is just finished biodiesel.
7.Methanol fine-distillation:after biodiesel is isolated,the remaining methanol liquid is distilled to form methanol.Cooled methanol can be reused.
Animal&vegetable oil and acid oil can be used to make biodiesel.Biodiesel is novel green fuel,there are following featurers:
1.Good driving performance for low-temperature motor,cooling point can reach -10°c without adding agent
2.Good lubrication performance ensures low wearing rate of oil spraying pump,engine tank and rods
3.As flash point of biodiesel is higher than mineral diesel,biodiesel does not belong to dangerous goods.
4.Sulfur content is low,small emission
5.low residual combustion char(0.02%),i.e. microparticles content of waste gags is low.
6.Damage of waste gas after combustion is lower than that of mineral diesel
7.High biodecomposition rate is favorable for environment protection.
Animal&vegetable oil and acid oil can be used to make biodiesel.Biodiesel is novel green fuel,there are following featurers:
1.Good driving performance for low-temperature motor,cooling point can reach -10°c without adding agent
2.Good lubrication performance ensures low wearing rate of oil spraying pump,engine tank and rods
3.As flash point of biodiesel is higher than mineral diesel,biodiesel does not belong to dangerous goods.
4.Sulfur content is low,small emission
5.low residual combustion char(0.02%),i.e. microparticles content of waste gags is low.
6.Damage of waste gas after combustion is lower than that of mineral diesel
7.High biodecomposition rate is favorable for environment protection.
