Vegetable Oil Solvent Extraction Plant
Vegetable Oil Solvent Extraction Plant can process all kinds of oilseeds ,nuts ,fruit which has certain oil.It is a complete process.In general,it has three process as follow:
Oil pretreatment and oil prepressing equipment of Vegetable Oil Solvent Extraction Plant
Process characteristics
1, provide the appropriate production environment
2,try our best to minimize grease total losses, improve the oil yield , increase production and improve the quality of oil and cake meal;
3, increase s comprehensive utilization for the impurities and residues;
4,pretectly match oil extraction production line, design different production process according to different
Raw material.
Oil Extraction Machine of Vegetable Oil Solvent Extraction Plant :
Requirements for extraction cake ,steam ,water. electricity etc:
Moisture of extraction material |
5-8% |
temperature of extraction material |
50-55°C |
oil content of extraction material |
50-55°C |
oil content of extraction material |
14-18% |
thickness of extraction cake |
less than 13mm |
powder porosity of extraction material |
less than 15% (30 mesh) |
steam |
more than 0.6Mpa |
solvent |
national standard No. 6 solvent oil |
electric powe |
50HZ 3*380V±10% |
Electric lighting |
50HZ 220V ±10% |
tempreture of supplement water |
less than 25°C |
Hardness |
less than 10 |
volume of supplement water |
1-2m/t raw material |
temperature of recycle water |
less than 32°C |
Oil Refinery Process of Vegetable Oil Solvent Extraction Plant :
1,continuous alkali refining shortens contact tome between oil and lye,which reduces oil saponification state,lowers refining consumption,and improves efficiency;
2,decolorization craft adopts technology of combining premixing and steam mixing bleaching,which improves bleaching efficiency,saves consumption of bleaching clay, and it is simple and convenient to operate ; besides,negative pressure state avoids oxygen in the air from contacting with hot oil,thereby ensuring oil product quality ,inhibiting with hot oil,thereby ensuring oil product quality,inhibiting acid value to rise again,and lowering peroxide value;
3,physical refining section adopts new type continuous deacidiffication and deodorization craft,which is applicable for vegetable oil of high acid value and low resin content,the actual production proves its most obvious advantages as following: strong deacidiffication ability ,excellent hot bleaching effect,high refining rate ,good oil quality etc.
Henan Huatai Cereals&Oil Machinery Engineering Co.,Ltd won "TOP 10 Cereals&Oil Machinery Brand in China" in 2011,which is the biggest professional manufacturer in set of oil machine for 22 years.
Quality and Service Commitment | |
|
Our company always put the interests of customers and product quality to the first place, and always adhere to the"no best,only better" as our purpose. We will be commitment to provide high quality products with perfect site services and after-sales service. Now the specific commitments are as follows: | |
1. |
Ensure to timely provide complete sets of equipment and accessories. |
2. |
Ensure that one-time installation debugging acceptance. |
3. |
To provide high quality material with preferential price. |
4. |
Priority to provide customer our new craftworks and products. |
5. |
Free training technological operator to ensure the trained staff can operation independently. |
6. |
In the installation process,we will appoint a installation supervision staff on the spot. |
7. |
we will offer an experienced project manager, organize a good installation team for the work of field installation debugging. |
8. |
After the equipment field assembly and installation, we will be also responsible for the single equipment debugging, online debugging and Feeding trial operation,to ensure that equipments can normal operate in full load conditions. We will provide all kinds of information and records according to the requirements of the bid. The qualified completion files will be provided to customers according to their requirements within one month after acceptance. |
9. |
In the warranty period, all because of the quality of products has caused the damage or failure of equipment, suppliers will take the responsibility for the free repair and replacing spare part. Due to the damage caused by the customer,we only charge material costs for repair and replacement. After the receipt of customers notice,we will suggests the method to solve problem within six hours, or send specialist to the site to solve the problem within twenty four hours. |
