Co2 Laser Treatment

Introduction:

10.4 inch big color touch LDC screen RF Vaginal +fractional+Normal  CO₂ laser  system

Applications:

1. Vaginal Tightening Laser

2. Fractional resurfacing CO₂ laser

Features& Advantages:

1. USA Coherent RF Excited CO₂ laser

2. 3 kinds of treatment mode

3. Adjustable scanning kinds of patterns and different sizes

4. Built-in blowing smoke system

5. Adjustable pulse duration

6. Automatic alarm Systems for operation and troubles

7. High return with no consumable costs

Specifications:

Wavelength: 10.6+ 0.1um

Beam Transmission System: 7-Articulation joint Spring-Balanced Light Guiding Arm.

Power:1--30W

Operate Mode:Vaginal , Fractional and Ultra Pulse

Indication Beam : Green Semiconductor Laser(532nm,<5m W)

Operating Interface: 10.4" TFT color screen

Scanning area :Max20x20mm(HFLS)

Scanning patterns Number: 7 kinds

Scanning patterns Type:

Rectangular, Square, Ellipse, Circle, Rect, straight line, hexagon and triangle

Cooling Systems: Air cooling

Treatment theory:

The CO2 laser produces a beam of infrared light with the principal wavelength centering around 9.4 and 10.6 micrometers. With fractional laser resurfacing, the laser beam is broken up or fractionated into many small micro beams which are separated. These small areas of untreated skin promote a much more rapid recovery and healing with less risk of complications. The small areas treated by the fractional micro beams, called micro treatment zones, cause sufficient laser injury to promote new collagen production and resultant facial skin rejuvenation.
