CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V

CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V thumbnail-1
CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V thumbnail-2
CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V thumbnail-3
CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V photo-1
CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V photo-2
CE Approved Handheld 1-channel Veterinary Electrocardiograph/EKG/ECG Machine EKG-80V photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, Physical testing
Model Number:
EKG-80V
Place of Origin:
Beijing, China
Contact Supplier Request Quote Chat Now
Beijing Carejoy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Physical testing
Model Number EKG-80V
Place of Origin Beijing, China

Features:

  • Hand-held single channel digital ECG machine with measurement report
  • Automatic and manual operation modes
  • LCD display ECG wave
  • AC/DC power, built-in rechargeable Ni-MH battery
  • Mini size, hand-held, portable, convenient for doctors’use anywhere

Specification:



Safety Mode

IEC60601-1 class I, type CF

Lead selection

Automatic and Manual

Operation mode

Automatic and Manual

Input circuit

Floating

Calibrating voltage

1mV ±5%

Input current

<100nA

CMRR

>103dB

A/D

12bit

Frequency response

0.05Hz-150Hz

Filter

AC: 50/60Hz      EMG:  35-4Hz

Skin voltage tolerance

±300mV

Sensitivity setting

5, 10, 20mm/mV, conversion deviation≤5%

Noisy level

≤15Vp-p

Display

LCD 160x96, visual size: 34x60

Recording system

Thermal-array printing

Noise level

≤15μVp-p

Power supply

AC: 220V+-10%       DC: 7.4 Lithium battery

Size

190x90x40mm

Weight

800g
