CE Approved Advanced Anesthesia Machine With Ventilator

CE Approved Advanced Anesthesia Machine With Ventilator thumbnail-1
CE Approved Advanced Anesthesia Machine With Ventilator photo-1
US$ 4,000 - 5,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Other, Anesthesia Equipments & Accessories
Brand Name:
OEM
Model Number:
AM-900A
Contact Supplier Request Quote Chat Now
Beijing Carejoy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing/ Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Anesthesia Equipments & Accessories
Brand Name OEM
Model Number AM-900A
Place of Origin Beijing, China
CE approved high-qualified Portable Anesthesia machine

Product Description



Features:

Anesthesia information management system output port
Owned power supply to support the work of the anesthesia machine for more than two hours

Host:
10.4 "color TFT screen display
Double-ended differential pressure flow sensor, machine control or manual mode can be real-time monitor the tidal volume, respiratory rate, airway pressure, pressure wave, the flow velocity waveform (bidirectional) on the pressure, the lower limit of suffocation, the oxygen concentration.
Breathing ring function
Can be closed, half-closed, half-open inhalation anesthesia
Scope: adults, children
Low gas source alarm: when oxygen gas source pressure is too low, will have more than seven seconds audible alarm
High-pressure limit: when airway pressure exceeds the upper limit set value, the ventilator automatically limited to stop the airway pressure continue going up to ensure patient safety.
Low-voltage protection: When the oxygen pressure is lower than 0.1MPa, the nitrous oxide pathway automatically cut off
Failure alarm, power failure continuation function
Rapid oxygen supply: 35 ~ 75L/min
Air source pressure: oxygen: 0.27 ~ 0.55MPa
Nitrous oxide: 0.27 ~ 0.55MPa
Air: 0.27 ~ 0.55MPa
Power supply: 220V ± 10%, 50Hz ± 1%

Flowmeter:
Oxygen, nitrous oxide, air six tube flowmeter (0 ~ 10L/min)
Oxygen / nitrous oxide linkage to ensure that the oxygen concentration not less than 25%
Anesthesia ventilator:
With each set of adults, children bellows
Pneumatic electrical control
Detection parameters: tidal volume, respiratory rate, respiratory ratio, peak airway pressure, airway pressure waveform
Operating modes: manual, automatic
The respiratory mode: IPPV, SIGH, SIMV/f/2, SIPPV PEEP (0.5 ~ 2KPa)
Tidal volume: 0 to 1500mL
Respiratory rate: 4 ~ 60bpm
Respiratory ratio: 1:0.5 ~ 1:4 adjustable
Synchronous trigger pressure: -1 ~ 0KPa
Pressure upper limit: 2 ~ 6KPa
Pressure lower limit: 0.6 ~ 2KPa

Breathing circuit:
Integrated design, integrated breathing circuit

Evaporator:
High-precision dual-evaporator, enflurane and isoflurane (also provide other optional evaporator)
Concentration adjustment range: 0.5 ~ 5% VOL
Evaporator has the flow, pressure, and automatic temperature compensation function
Self-locking and interlocking functions
Capacity: 180mL


Packaging & Shipping



Package: Standard export carton



Payment & Delivery:
T/T, West Union & Paypal.
Shipping: DHL, UPS or TNT etc, arrive in 3-5 working days.
Air shipping & sea shipping are also available.
Warranty: 18 months upon delivery.

Our Services



1. 18 months warranty for the mainframe from date of shipment under normal use and service.



2. On-line services, for example, technical consultancies provided by our skilled technique group concerning any question of the equipment, and after-sale maintenance and more.



3. Carejoy Medical provides free technical & service training to the technical & sales staff of distributors for the related products and will further provide technical assistance via e-mail, Skype as requested by the distributors. The training will be performed in Beijing China.


4. OEM/ODM services are available.

Company Information

 Our company has been a professional manufacturer & distributor for high-tech medical equipments since 2001.

We aim to provide the cost-effective, reliable performance products. By collaborating with famous universities and organizations, the company has designed and produced several types medical equipments in China market. The quality management system of Risingmed is ISO13485 certified. Our products are also CE certified by MedCert Germany CE 0482. We have won a considerable market share in China domestic market and a growing increase in international market.

We aim to build good business relationships with more international distributors and customers sincerely. Risingmed assures dealers and clients to continue provide products with innovative design, reliable quality, competitive prices and rapid & effective customer service.

We have many medical product categaries up to now:

Pulse Oximeter, Ultrasound Scanner, Patient Monitor, ECG, Holter, Fetal Doppler, Fetal Monitor, Endoscopes,  Operation lights, Operation tables,etc.
