1-10Hz Nd YAG Tattoo Removal Laser 1 HZ Machine The Best China Laser By Apolomed

1-10Hz Nd YAG Tattoo Removal Laser 1 HZ Machine The Best China Laser By Apolomed photo-1
1-10Hz Nd YAG Tattoo Removal Laser 1 HZ Machine The Best China Laser By Apolomed photo-2
1-10Hz Nd YAG Tattoo Removal Laser 1 HZ Machine The Best China Laser By Apolomed photo-3
1-10Hz Nd YAG Tattoo Removal Laser 1 HZ Machine The Best China Laser By Apolomed photo-4
1-10Hz Nd YAG Tattoo Removal Laser 1 HZ Machine The Best China Laser By Apolomed photo-5
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Laser Type:
Nd: Yag Laser
Q-Switch:
Yes
Style:
Portable
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Laser Type Nd: Yag Laser
Q-Switch Yes
Style Portable
Certification CE1023/FDA registered/ISO13485
Place of Origin Shanghai, China
Brand Name Med-Apolo
Model Number HS-220
Feature Pigment Removal, Skin Rejuvenation, Tattoo Removal

Application of q swithched nd yag laser tattoo removal machine:

ND YAG laser :  tattoo/eye embroidery/eyeline/freckles removal and skin whitening.

1064nm wavelength: get rid of freckles and yellow brown spot, eyebrow tattoo, failed eye line tattoo, tattoo, Birthmark and Nevus of Ota, pigmentation and age spot, nevus in black and blue, scarlet red, deep coffee and etc. deep color.

532nm wavelength: get rid of freckles, eyebrow tattoo, failed eye line tattoo, tattoo , lips line, pigment, telangiectasia in shallow red, brown and pink and etc. light color. pigment removal.

1320nm Professional  for skin rejuvenation and face deep cleaning , blackhead removal, skin tightening and whitening, skin rejuvenation.


Nd YAG tattoo removal laser machine the best China laser by Apolomed

Nd YAG tattoo removal laser machine the best China laser by Apolomed by Apolomed

Brief description



  • Factory direct sale Q-Swtich Nd:YAG laser machine
  • Single laser rod and double rods optional
  • Zoom lens 1~5mm and beam expander 7mm available
  • Strong and Stable energy output
  • Air & Water circulation cooling system with copper radiator
  • Luxry 8" true color touch screen with multi-languages
  • IC card and USB function supported
  • 1064/532nm Q switched Nd:YAG laser tattoo removal machine and pigmentation removal

Nd YAG tattoo removal laser machine the best China laser by Apolomed



Applications





1. Principle:
Q-Switched Nd:YAG Laser system,with the advanced laser technology, could make the skin selectively absorbing certain wavelength of laser and achevie curative effect.

Nd YAG tattoo removal laser machine the best China laser by Apolomed

2.  Application:
2.1   1064nm: birth mark, coffee spot, freckle, senile plaque, pigment from outside injure, black, blue tattoo, eye line, eye brown and lip line etc.

2.2    532nm: red and brown pigment, red spot and mole, capillarectasis and brandy nose.



Apolomed best laser tattoo removal machine, also used for skin rejuvenation Nd YAG tattoo removal laser machine the best China laser by Apolomed



Specifications



3. Technical specifications of Nd YAG tattoo removal laser machine the best China laser by Apolomed



Advantage:

1.touch screen

2.high power

3.two main board(energy stable control)

light guidance

5.Separable connector

6.Powerful cooling system(guarantee the long time working)


Feature and Benefits:
1) Innovative in laser technology, strict in technical detection, precise in manufacture.
2) Special designed cooling system ensures constantly working.
3) New fashionable outlook design.
4) Portable and aseismatic, convenient for transportation.
5) No injury to normal tissue.
6) Remove pigmentation without side effects or scar.
7) Accurate infrared indication light makes the spot position more accurately and increases the utilization of light point

Laser type



1064/532nm Q-Switched Nd:YAG Laser



Wavelength:



1064nm,532nm



YAG Bar:

  φ7 / φ6+7mm ( optional)


Treatment head:



Zoom tip 1064 and 532nm,   treatment tip for skin rejuvenation



Pulse Width:



<10ns



Repeat rate:



1-10HZ



Spot size:



1~5mm



Energy:



360~1200mJ (for φ7 )/600~1600mJ(for φ6+7mm)



Operate interface:



7" or 8” True color TFT touch screen



Cooling system:



Air & water circulation cooling system



Power Supply:



AC100V or 230V, 50/60Hz



Dimension:



44*37*105(L*W*H)



Weight:



35kgs





Q-Switch Nd YAG laser handpiece and tips:

Nd YAG tattoo removal laser machine the best China laser by Apolomed



Advantage



Advantages of Apolo Q-Switch Nd:YAG laser:

  •  Stable, reliable and powerful laser output
  •  Excellent performance without side effects
  •  Effective air and water  cooling system allowing constantly working for 12 hours
  • Easy after service: Software upgrade is done via USB. It is a compact and modulariged design with metal chassis. Easy for maintenance.
  • Localization with 16 languages, meets the requirement of global market.
  • Operations Safety: water flow and water level control system keeps laser machine in safe condition.
  •  Installation is simple with plug and play connectors.
  • Obtained CE Medical certificate

 Nd YAG tattoo removal laser machine the best China laser by Apolomed



Company Information

Nd YAG tattoo removal laser machine the best China laser by Apolomed

Nd YAG tattoo removal laser machine the best China laser by Apolomed

Nd YAG tattoo removal laser machine the best China laser by Apolomed

Nd YAG tattoo removal laser machine the best China laser by Apolomed

Nd YAG tattoo removal laser machine the best China laser by ApolomedNd YAG tattoo removal laser machine the best China laser by Apolomed



Contact us



Related products:



Nd YAG tattoo removal laser machine the best China laser by ApolomedNd YAG tattoo removal laser machine the best China laser by Apolomed

Q swithced nd yag laser working Principle:
The energy of Q-switched ND:YAG laser can be absorbed by the blue and black melanin.The melanin will be fragmented so small that they can be metabolized by the lymphatic system or egested out of the body. Thus the tattoo or other pigmentations will be removed without damage to normal tissue.The treatment is safe and convenient without downtime and side effects.
