Hospital use patient cardiac/blood pressure monitor
Portable multiple parameters patient monitor is a kind of medical device advance in innovative structure, small size and AC-DC, configuring batteries inside and handles help care for patient shifting. Abundant function could invigilating and measuring heart rate, NIBP (noninvasive blood pressure), breath, ECG, blood oxygen saturation(Spo2), temperature and vital signs.
Comprisal
12.1/15 inch LCD screen
Electrocardiograph monitoring
Heart rate monitoring,
Respiration monitoring,
NIBP monitoring,
Blood oxygen saturation monitoring,
Bidirectional temperature monitoring, etc.
Technical parameter
|
Alarm system
|
Automatic audible and light double alarming include alarming review. upper limit and lower limit could modulate
|
|
ECG
|
Optional standard three or five leads cable Three leads: RA, LA, LL. Lead I,II and III Five leads: RA, LA, LL, RL, V. Lead I, II, III, aVR, aVL and aVF. Gain select: ×0.25, ×0.5, ×1, ×2 Heart rate range: Adult(15-300bpm/min) infant/children (15-350bpm/min) Electric current leakage: less than 10μA Protection: 4000V, 50/60Hz isolation & withstanding voltage capacity Anti-defibrillation protection: Anti high frequency electrotome interference Resolution:1 bpm Accuracy: ±1% Arrhythmia analysis & review: Available
|
|
Respiration rate
|
Method: RA-LL impedance Testing range: Adult(7~120BrPM) Children and neonate (7~150 BrPM) Resolution: 1 BrPM Accuracy rate: 2 BrP Asphyxia monitoring alarm: available
|
|
NIBP
|
Testing method: Automatic oscillography Testing mode: hand-actuated, fast, STAT Auto time testing: available Testing unit: mmHg/Kpa Testing type: systolic pressure, diastolic pressure, mean blood pressure Applicative crowd: adult, children, infant Resolution: 1 mmHg Accuracy rate: 8mmHg Static pressure accuracy: 3mmHg Overvoltage protection: available
|
|
Blood oxygen saturation (Spo2)
|
Testing range: 0~100% Resolution: 1% Accuracy rate: 2%(70~100%);3%(0%~69%)
|
|
Pulse rate
|
Testing range: 15~300bpm Resolution: 1bpm Accuracy rate: 2bpm
|
|
Temperature
|
Range: 0~50 centigrade Resolution: 0.1 centigrade Accuracy rate: 0.1 centigrade Channel: Double |
Selective configuration
1.End-tidal carbon dioxide (ETCO2) |
|
CO2 testing range: 0-13%(0-100mmHg) CO2 testing accuracy: < 5.0% CO2, ± 2 mmHg; > 5.0% CO2, 10% of value. Respiration rate: 3~150 BPM Respiration testing accuracy: 1% ±1BPM Flux control: 50~250ml/min adjustable
|
2.Recorder |
|
Specification: build-in, heat array Waveform tracings: single leads, three leads Recording: hand-actuated, alarming, timing Chart speed: 12.5mm/s,25mm/s,50mm/s
|
Feature
- 12.1/15 inch real color, wide vision, high luminance LCD screen
- User-friendly display interface, easy operation
- Large capacity rechargeable internal battery to facilitate patient transfer.
- Browsing & playback function for long time waveform monitoring data record
- Automatic audible and light alarming
-
Anti-defibrillation, Anti high frequency electrotome interference
Accessories
1. host machine
2. 5 leads ECG electrode cable one set (include respiration and temperature probe)
3. Adult blood pressure cuff
4. blood pressure extension tube
5. Adult blood oxygen probe
6. Power adapter
7. ECG electrode slices one bag(20 pieces)
8. User manual
Product Display
Warranty
We offer one year free maintenance for host machine
We guarantee quick and efficient service and maintenance of our device security solutions around the world. We ensure that we will be there whenever or wherever you need us, 24 hours a day, 365 days a year. Like all Onity solutions, our products are backed by a commitment to provide superior global service with local support. we can help you work and reach your goals.
