AES/EBU Switcher
US$ 758 - 758
/ Piece
1 Piece(Min. Order)
- Shanghai
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | ZHC | |
| Model Number | ZHC842D |
Product Description
Specifications
AES/EBU Switcher,4-input changeover automatically,
minitor output,
changeover time can be programmed by user.
ZHC842D has four routs of AES/EBU digital audio input,one route or two routes of AES/EBU digital output,one route of simulated stereo monitor output,and RS485(232)control interface,which can be switched by remote control.
Supporting AES/EBU professional format;the highest sample rate can reach 192KHz.
Automated changeover
Three ways of switching:manual,automatic and remote control.
Optional switching delay time;users can set various lengths of switching delay time on the front panel according to their own needs.
Power failure direct stereo and manual direct stereo functions.
Can detect such digital audio errors as the losign lock of signals,CPC and parity check.
Provide RS485 or PS232 serial communication control interface.
The sample rate of input and output remains unchanged.
Technical specification:
| 1, | AES/EBU | 110Ω,XLR balance(AES-1992) |
| 2, | Sample rate | 32KHz~96KHz |
| 3, | Synchronous mode | inner |
| 4, | analog output | balance stereo |
| 5, | Audio response | 0.1dB,20Hz~20KHz |
| 6, | Distortion | less than 0.1%,20Hz~20KHz |
