Wirewound 0.5R 2R 50R 250R 500 Ohm Precision Fuse Power Resistor

Wirewound 0.5R 2R 50R 250R 500 Ohm Precision Fuse Power Resistor thumbnail-1
Wirewound 0.5R 2R 50R 250R 500 Ohm Precision Fuse Power Resistor thumbnail-2
Wirewound 0.5R 2R 50R 250R 500 Ohm Precision Fuse Power Resistor photo-1
Wirewound 0.5R 2R 50R 250R 500 Ohm Precision Fuse Power Resistor photo-2
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Pakheng
Model Number:
FKN
Contact Supplier Request Quote Chat Now
Shenzhen Pak Heng Electronics Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Pakheng
Model Number FKN
Type Fuse Resistor
Technology Wirewound
Package Type Other
Resistance 0R1-56R
Resistance Tolerance 2% 5% 10%
Rated Power 1/2W 1W 2W 3W 5W 6W 7W 8W 10W
Temperature Coefficient 300ppm/℃
Operating Temperature -55 to +275.

FKN Wirewound 0.5R 2R 50R 250R 500 ohm Precision Fuse Power Resistor



 Wirewound 0.5R 2R 50R 250R 500 ohm Precision Fuse Power Resistor

Wirewound Fuse Resistor FKN

Feature:

1,Good heat-durability,low temperature coefficient, low noise,high overload power.nonflammability.

2, Can be Fusible during the stated time for protecting the circuit once wording at the required overload voltage.

3,Operating ambient temperature:-55 to +275.

4,The surface is gray white nonflammable coating and indicate a white ring at the behind of the precision color ring.

5,Resistance tolerance:±5%,±10%



Performance Test:

1,Temperature coefficient    :   ±300ppm/C

2,Short time overload    :         R≤±(2%R0+0.05R)

3,Pulse overload    :                R≤±(1%R0+0.05R)

4,Resistance to soldering heat   :     R≤±(1%R0+0.05R)

5,Solerability    :                    The soldering area is over 95%

6,Temperature cycling    :       R≤±1%(1%R0+0.05R)

7,Load life in humidity     :      R≤±1%(1%R0+0.05R)

8,Load life in heat     :            R≤±1%(1%R0+0.05R)

Cement Resistor

Wirewound 0.5R 2R 50R 250R 500 ohm Precision Fuse Power Resistor
