Cctv DVI Video Transmitter Support KVM up to 10km

Cctv DVI Video Transmitter Support KVM up to 10km photo-1
Cctv DVI Video Transmitter Support KVM up to 10km photo-2
Cctv DVI Video Transmitter Support KVM up to 10km photo-3
Cctv DVI Video Transmitter Support KVM up to 10km photo-4
Cctv DVI Video Transmitter Support KVM up to 10km photo-5
US$ 1 - 240 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Pway
Model Number:
PW-THF109DKM
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Pway
Model Number PW-THF109DKM

cctv DVI video transmitter support KVM up to 10km cctv DVI video transmitter support KVM up to 10km





Product Description

Descpription



The DVI KVM Fiber optic extender provides extension of DVI signals long distances over one fiber optic cable, it supports high resolution up to 1080P, KVM, RS232 signal and external audio transmission function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.



Features

  • Transmits DVI video signals up to 10km over one fiber optic cable;
  • Support video resolution up to 1920*1080@60Hz;
  • Support keyboard and mouse signal transmission;
  • Support external stereo audio unidirectional transmission;
  • Support RS232 signal unidirectional transmission, baud rate self-adaptive;
  • Compliance with DVI 1.0 and HDCP 1.2 standard;
  • High compatibility, can auto-match source and display device;
  • Built-in automatic adjustment system, make the image smooth, clear and stable;
  • Built-in ESD protection system;
  • Simple to install, plug and play;
Pictures
cctv DVI video transmitter support KVM up to 10kmcctv DVI video transmitter support KVM up to 10kmcctv DVI video transmitter support KVM up to 10km
Specification


Parameter

Description

Video

Standards

DVI 1.0; HDCP 1.2

Maximum pixel clock

165MHz

Maximum data rate

6.75Gbps

Resolution

1920*1080@60Hz  1920*1080@50Hz

1920*1080@30Hz  1920*1080@25Hz

1920*1080@24Hz

1080I@60Hz  1080I@50Hz

1280*720@60Hz    1280*720@50Hz

Connector

DVI-D

Impedance

100Ω

Audio

Interface

3.5mm earphone seat

Signal type

Stereo

K/M

Interface

To PC: MINI-USB

To keyboard and mouse: USB-A

RS232

Interface

Industrial terminal

Signal direction

Unidirectional

Baud rate

Self-adaptive, Max:115200bps

Data bits

8

Optical fiber

Interface

LC connector

Fiber type

Single-mode single fiber

Wavelength

Single-mode 1310nm

Interface bandwidth

2.97Gbps

Transmission distance

standard 10km

Other

Power supply

The power adapter: DC 5V/2A

Power dissipation

MAX 6W

Temperature

Operating: -5 ~ +70

Humidity

Operating: 5% ~ 90%

Dimension

136*130*30mm

The warranty

1 year free warranty





Panel





Port name

Description

DVI IN/OUT

DVI signal input/output

Audio IN/OUT

Stereo audio signal input/output

RS232

Serial port( G: Ground, T: transmit, R: receive )

DC/5V

Power adapter socket

FIBER

SFP module---LC connector

K/M TO PC

Mini-USB connect to PC

KEYBOARD/MOUSE

USB connect to keyboard and mouse

LED indicator

Description

VIDEO

Video signal connection indicator

LOCK

Video signal lock indicator

RUN

System status indicator

POWER

System power indicator

 Installation

  1. Connect the provided DC/5V power supplies to the power socket of the transmitter and the receiver,
  2. Connect an DVI cable between the DVI input port of transmitter and the DVI output port of the video source,
  3. Connect the DVI output port of receiver to the display device with DVI cable,
  4. Connect the transmitter optical port to the receiver optical port using one fiber optic cable.
