RS232 Sdi in Vga Out Digital tv Converter Box Wifi

Name: RS232 Sdi in Vga Out Digital tv Converter Box Wifi
Brand: Pway
SKU: 135021729
Availability: InStock

RS232 Sdi in Vga Out Digital tv Converter Box Wifi thumbnail-1

RS232 Sdi in Vga Out Digital tv Converter Box Wifi photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Pway

Model Number:

SC5810HV

Place of Origin:

Guangdong, China

Contact Supplier Request Quote Chat Now

Shenzhen City Pin Wei Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Pway

Model Number SC5810HV

Place of Origin Guangdong, China

Product Description

RS232 sdi in vga out digital tv converter box wifi

Features

SDI input formats supported: Supports SDI input format: (full format, any SDI format)
SD: 525i @ 59.94Hz, 625i @ 50Hz
HD: 720p @ 23.98Hz / 24Hz / 25Hz / 29.97Hz / 30Hz

720p @ 50Hz / 59.94Hz / 60Hz

1080i @ 50Hz / 59. 94Hz / 60Hz

1080p @ 23.98Hz / 24Hz / 25Hz / 29.97Hz / 30Hz

3G: 1080p @ 50Hz / 59.94Hz / 60Hz

Support SMPTE 425M (A grade and B grade), SMPTE424M,SMPTE292M,SMPTE259M-C
With 1 SDI loop out
Support OSD and menu interface
Automatic detection HDMI EDID information, the best mode of adaptive HDMI
Convert all formats supported asymmetric
Blue warning signal loss
VGA can specify the output format: 720p/1080p
Automatically de-embedded SDI signal to HDMI audio signal in
Support AV (CVBS) signal output (PAL / NTSC system optional)
Remote support user choice forced output mode

HOT SALE SDI Converter

Product Model	PW-SC5810HV
Input Interface	1×BNC SDI
Input Signal Type	SD-SDI(270Mbps),HD-SDI(1.485Gbps), 3G-SDI(2.97Gbps)
Supported input format	525i 59.94,625i 50 720p 23.98/24/25/29.97/30/50/59.94/60 1080i 50/59.94/60 1080p 23.98/24/25/29.97/30/50/59.94/60
SDI signal amplitude	0.8Vp-p
SDI impedance	75 Ohm
SDI coupling type	AC Coupling
SDI jitter (typical value)	SD-SDI≤0.1UI HD-SDI≤0.2UI 3G-SDI≤0.4 UI
Maximum input cable length	Belden 1694A: SD-SDI 400m,HD-SDI 200m,3G-SDI 140m Note: the differences between the said transmission distance for different specifications of the cable, test results
SDI loop out Interface	1×BNC SDI
HDMI output interface	1×HDMI
VGA output	1×VGA
Frequency bandwidth	165MHz/ Standards compliant(HDMI 1.3)
Dimensions (mm)	15411936
Power requirements	5~24VDC

Instructions for use

Application
