CNG CYLINDER

CNG CYLINDER thumbnail-1
CNG CYLINDER photo-1
US$ 150 - 399 MOQ: 200 Units
Key Specifications
Get Latest Price
Material:
Other, 30CrMo/34CrMo, 30CrMo/34CrMo
Use:
Other, cars/trucks or others
Pressure:
High
Contact Supplier Request Quote Chat Now
Shandong Mengling Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO/SHANGHAI/NINGBO/TIANJIN..
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, 30CrMo/34CrMo, 30CrMo/34CrMo
Use Other, cars/trucks or others
Pressure High
Place of Origin Shandong, China
Brand Name MENGLING
Model Number CNG II--325/356/406

CNG CYLINDERCNG CYLINDEROur

 WRAPPED CYLINDER---SHANDONG MENGLING GROUP CO.,LTD

      The Steel Liner Hoop-wrapped CNG tank for Vehicles is designed and manufactured by our company.This kind of cylinder is composed of steel liner and circumferential winding layer.The product introduces advanced equipments and techniques,and fully meets the requirements of international standard ISO11439:2000.By applying the techniques of the CNG fiber winding and constant temperature curing,the product has high quality and best appearance.The product has advantages of big diameter,large volume,light weight,high safety and low service expenses. Furthermore, it is widely used  in cars ,buses and trucks.





 DETAILS

Name  CNG Cylinder
Type CNG2-G-325/356/406-V-20B
Length 795-1970mm
Materials High quality steel 30CrMo,Fiberglass,Resin
Technics Standardized production
Certificates ISO11439:2000 , BV and SGS
Accessories Valve(QF-5T/QF-T1)or depend on customer's requirements
Standards ISO11439:2000,CQC ,ECE
Packaging The packing methods of the cylinder is according to the needs of different customers,bunding or carton is available.
Service Life  The cylinder is refillable with natural gas with service lifetime of 15 years under the right way with operation instructions.



 Type1:CNG2-G-325-V-20B

Nominal Water Capacity(L) 45 50 55 60 65   70 80 90 120
Length of Cylinder (mm)  725  790  855  915 980  1050  1175 1305  1690
        Weight(kg)  38  41  44  47  50  53  60  67  86
Inner Liner Diameter (mm)   325 325     325 325   325   325 325   325   325
Cylinder Diameter (mm)   335     335   335     335  335   335   335     335     335



Type2:CNG2-G-356-V-20B

Nominal Water Capacity(L) 65 70 75 80 90 100 140
Length of Cylinder (mm) 855 910 960 1015 1120 1230 1665
Weight(kg) 51 55 58 61 68 75 99
Inner Liner Diameter (mm)   356   356 356 356 356 356   356
Cylinder Diameter (mm)   367   367 367 367 367 367   367



Type3:CNG2-G-406-V-20B

Nominal Water Capacity(L) 72 80 85 90 100 120 210 230
Length of Cylinder (mm) 770 835 875 915 1000 1165 1935 2105
Weight(kg) 59 65 68 70 77 92 155 173
Inner Liner Diameter (mm) 406   406 406 406 406 406 406   406
Cylinder Diameter (mm) 419 419 419 419 419 419 419   419
