7 inch portable external push button video wall indoor use battery power media player car digital media player

FOB Price

USD $40 - $80 / Piece

1 Piece(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port Ningbo port
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Zhejiang, China	Brand Name:	OEM ODM	Model Number:	PT070D-6 (push button)
Type:	TFT	Application:	Indoor	Panel Size:	185 * 105 * 25 mm
Max Resolution:	800*3(RGB)(W) X 480(H)	Viewing Angle:	70(Right)/70(Left)/50(Top)/70(B0ttom)	Pixel Pitch:	0.107(W)*0.370(H)
Color:	16.7m(RGB 8 bit)	Contrast Ratio:	500:1	Brightness:	250cb/m
Response Time:	10msec	Input Voltage:	≤12W

Product Description

Specifications

1.Auto playback all/ folder repeat play
2.Support SD, USB, CF
3.Auto power on/off
4.CE, FCC, ROHS
5.Make personalized and cu

7 inch portable external push button video wall indoor use battery power media player car digital media player

Model: PT070D-6 (push button)

Item: 7inch poster push button LCD advertising player

4 FUNCTION MODES
You could choose one parameter from the below 4 function modes (Mode A,B,C or D). Note : We also could customize according to your supply parameters
A. There can be 3 buttons 4 file folders (folder 00,01, 02, 03), corresponds to 3 buttons (k1, k2, k3). Folder 00 is played as homepage.If you push either button, it will play the files in the corresponding folder, when the display of this folder finished, it will loop play the files in folder 00. For example, if you press button "k1", it will play files in folder 01. And if you press button "k1" again during the process of play, it will replay from the first file in folder 01. When it finished playing files in folder 01, it will turn to loop play files in folder 00. If you press button "k2" during the process of playing files in folder 01, it will turn to play files in folder 02. If no button being pressed it will also loop play the files in folder 00.
B. There can be 3 buttons which are corresponding to 3 file folders (folder 01, 02, 03) in the memory card. There is no Folder 00. If you push either button(from button k1 to k3), it will play the files in the corresponding folder, when the display of this folder finished, it will turn to a black screen. Only if you press the button "k3", it will loop play files in folder 3 all the time. If no button being pressed it will also be a black screen.
C. There can be 3 buttons. There should be 4 folders in the memory card, folder 00, 01, 02, 03. It will loop play files in folder 00 when power on. Press either button, it will loop play the files in the corresponding folder. For example, when you press button "k1", it will loop play files in folder 01 all the time.
D. There can be 3 buttons. There should be 4 folders in the memory card, folder 00, 01, 02, 03. And the 00 folder is played as homepage. Press either button, it will play the files in the corresponding folder. During the process of playing files, it is ineffective to press other buttons (there will be a palm in the top left of the screen as a reminder). Only when the media player finished playing the files in the corresponding folder, and turn to loop play files in folder 00, it is effective to press other buttons.
Single repeat, All repeat
Auto-play when turned on with the cards/USB inserted; Supports 16 kinds of auto play
BGM mode (Auto-boot mode can be set): Support background music
Pictures can be rotated 90°( Vertical display)
Super time switch function, can auto turn on/off at a specific time
One key copy
Picture Display Time: Picture Display Time is modifiable
Time Display: Time Display or not is modifiable
Full function remote control, easy operation
Multi-Language OSD: Chinese, English, Japanese, French, German, Danish, Spanish

Display	Resolution	800*3(RGB)(W) x 480(H) (digital panel)
	Luminance	250cd/m²
	Contrast Ratio	500:01:00
	Viewing Angle	+70/-70 (H), +50/-70(V) (degree)
	Backlight	LED back light
	Display mode Optional	16:9 / 4:3
I/O	AC Power Input	AC: 100~240 V
	DC Power Output	12V / 1.5A
	Integrated Speakers	2W x 2
Supported Card & Format	Interface	MMC/CF/SD/USB(2.0)
	Photo	JPEG, BMP
	Video	MPEG 1, MPEG 2, MPEG 4, AVI, MP4, VOB
	Audio	MP3, WMA
Other	Dimensions (LWH)	185 x 105 x 25mm not include bracket
	Shell Color	Default color: pearl white; optional
	Shell Color	color: blue, black...etc
	Accessories	Bracket(optional), remote control,
	Accessories	user manual, AC adapter
	Operating temperature	0°C~ 40°C (32°F~104°F)
