good price brass screw pcb terminal block connector 3.5mm pitch
Pitch: 2.54mm,3.5mm,3.81mm,3.96mm,5.0mm,5.08mm,7.5mm,7.62mm, 8.25mm, 8.5mm, 9.5mm, 10mm, 11mm, 13mm etc
Material
Screws: M2.5 steel Zinc plated
Wire guard: Phosphor bronze, Ni plated
Pin header: Brass, Tin plated
Housing: PA66, UL94V-0
Electrical
Rated voltage: 300V
Rated current: 10A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding voltage: AC 2000V/1 Min
Wire range: 24-12AWG 2.5MM2
Mechanical
Temp. Range: -40~ +105
MAX Soldering: +250, for 5 Sec.
Torque: 0.4Nm(3.6lb.in)
Strip length: 6-7mm
Dongguan City Fooconn Electronic Products Co., Ltd. which is a collection of mold design and manufacturing, metal stamping, plastic injection molding, product assembly, wire connectors and wires manufacturing company. Products are widely used in computers, computer peripherals, servo, industrial control, safety defense, mechanical, communications, medicine, etc. More than 10years experience in Connector Area.
Our Office
Our Meeting Room
Our Workshop
Our Facility
Packaging:
1) Packed in tube/PE Bag/Tape&Reel/Tray/Plastic Box ,and cartons (bulk package )
2) Private packing and label service are available as per your requirement
Shipping:
1.The items can be sent within 7-10 working days after we received the payments.
2.As for mass production, we will confirm the delivery in advance.We will send you’re the products by SF/UPS/DHL/TNT/ FedEx.
What service do you have and why choose you?
- OEM and ODM
- CE/FCC/Rohs both approved.
- 100% QC inspection before shippment.
- The best production capability, best quality control, best service are our core competitiveness.
Q: What is the Minimum Order Quantity(MOQ)?
A: Normally, MOQ is 100pcs, but special requirements can be accepted.
Q: How much do I need to pay for your OEM service?
A: No need to pay extra cost for our OEM service if order quantity over 1000 pcs. The OEM cost includes in the unit price.
Q: What is the lead time?(How long do you need me to prepare my goods?)
A: 2-4 days for sample orders, 10-15 days for mass production orders (based on different quantities, OEM , etc.)
Q: How will you deliver goods to me?
A: We ship by air and sea generally. In the mean time, we cooperate with international expresses such as DHL, UPS, FedEx, TNT to enable our customers to get their goods rapidly.
Q: How long do I need to wait before my goods arrive?
A: 5-7 days for air transportation, 3-5 days for international express.
Q: How is your product quality?
A: Our raw materials are purchased from qualified suppliers. And we have a strong quality control team to guarantee our quality according to AQL standard. Fooconn always care what you care!
Q: What is your warranty?
A: Our warranty is 12 months after delivery, Fooconn pays high attention to after-sales service.
