25W Mini-Size Switching Power Supply

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

X&Y

Model Number:

BS-25W

Yueqing Xinyang Automation Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name X&Y

Model Number BS-25W

Output Power 1 - 50W

Output Type Single

Input Voltage Other, Universal AC input: 85-264VAC

Output Voltage 12v

Specifications

Single input 25W power supply
Mini size:110*78*35mm
Universal AC input: 85-264VAC
100% full load burn-in test

Single input 25W power supply

Specification	BS-25-5	BS-25-12	BS-25-15	BS-25-24
DC output	5V 5A	12V 2.1A	15V 1.7A	24V 1.1A
Wave and noise	50mVp-p	50mVp-p	75mVp-p	75mVp-p
Inlet stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±0.5%	±0.5%	±0.5%
Efficiency	72%	76%	77%	80%
Adjustable range for DC voltage	±10%	±10%	±10%	±10%
AC input voltage range	85-264VAC 47-63Hz 120-370VDC
AC Inrush current	Cold-start current 15A/115V 30A/230V
OverLoad protection	105%-150% hiccup mode,auto-recovery
Over-Voltage protection	115%-135% rated output voltage
Setup,rise,hold up time	300ms,50ms,80ms at full load and 230VAC
Withstand voltage	I/P-O/P:3Kv I/P-FG:1.5KV O/P-FG:0.5KV 1minute
Isolation resistanc	I/P-O/P IP/FG OP-FG:500VDC/100M
Working temperature	-10ºC—+50ºC
Safety Standards	Design refer to GB4943,UL60950,EN60950
EMC Standards	Design refer to GB9254,EN55022 Class B
Weight	0.39Kg
