35W Switching Power Supply

35W Switching Power Supply thumbnail-1
35W Switching Power Supply photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
X&Y
Model Number:
S-35
Contact Supplier Request Quote Chat Now
Yueqing Xinyang Automation Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name X&Y
Model Number S-35
Output Power 1 - 50W
Output Type Single
Input Voltage Other, Universal AC input: 176V~264V
Output Voltage 12v

Specifications

Single input 35W power supply
Mini size:129*97*38mm
Universal AC input: 176V~264V
100% full load burn-in test

Single input 35W power supply





Specification

     S-35-5

   S-35-12

    S-35-15

    S-35-24

DC output

     5V  7A

   12V  3A

 15V   2.4A

  24V 1.5A

Wave and noise

   50mVp-p

  50mVp-p

  50mVp-p

  50mVp-p

Inlet stability

     ±0.5%

     ±0.5%

      ±0.5%

     ±0.5%

Load stability

     ±1%

     ±0.5%

      ±0.5%

     ±0.5%

Efficiency

       70%

        76%

        78%

      78%

Adjustable range for DC voltage

     ±10%

     ±10%

      ±10%

     ±10%

AC input voltage range

85-132VAC/170-264VAC  47-63Hz

AC Inrush current

Cold-start current  18A/115V  36A/230V

OverLoad protection

105%-150% hiccup mode,auto-recovery

Over-Voltage protection



Setup,rise,hold up time

200ms,100ms,30ms at full load and 230VAC

Withstand voltage

I/P-O/P:3Kv    I/P-FG:1.5KV   O/P-FG:0.5KV   1minute

Isolation resistanc

I/P-O/P   IP/FG   OP-FG:500VDC/100M

Working temperature

-10ºC—+50ºC

Safety Standards

Design refer to GB4943,UL60950,EN60950

EMC Standards

Design refer to GB9254,EN55022 Class B

Weight

0.4Kg
