Help Center45W DIN RAIL Power Supply
Related Products
-
15W Dual Output Power SupplyNegotiableMOQ: 100 Pieces -
25W Mini-Size Switching Power SupplyNegotiableMOQ: 100 Pieces
-
120W Triple Output Power SupplyNegotiableMOQ: 100 Pieces
-
Small Size 75W Power SupplyUS$ 5 - 15MOQ: 100 Pieces
-
15W 24v Mini Size Switching Power SupplyUS$ 5 - 15MOQ: 100 Pieces
Specifications
Din rail switching power supply 45WMini size:110*78*35mm
Universal AC input: 96V~264V
CE approved, 2 years
45w din rail switching power supply
Specification |
BDR-45-5 |
BDR-45-12 |
BDR-45-15 |
BDR-45-24 |
DC output |
5V 5A |
12V 3.5A |
24V 1A |
24V 2A |
Wave and noise |
75mVp-p |
75mVp-p |
75mVp-p |
75mVp-p |
Inlet stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
Efficiency |
72% |
77% |
77% |
80% |
Adjustable range for DC voltage |
±10% |
±10% |
±10% |
±10% |
AC input voltage range |
85-264VAC 47-63Hz 120-370VDC |
|||
AC Inrush current |
Cold-start current 15A/115V 30A/230 |
|||
OverLoad protection |
105%-150% hiccup mode,auto-recovery |
|||
Over-Voltage protection |
115%-135% rated output voltage |
|||
Setup,rise,hold up time |
300ms,50ms,80ms/230VAC |
|||
Withstand voltage |
I/P-O/P:3Kv I/P-FG:1.5KV O/P-FG:0.5KV 1minute |
|||
Isolation resistanc |
I/P-O/P IP/FG OP-FG:500VDC/100M |
|||
Working temperature |
-10ºC—+50ºC |
|||
Safety Standards |
Design refer to GB4943,UL60950,EN60950 |
|||
EMC Standards |
Design refer to GB9254,EN55022 Class B |
|||
Weight |
0.31kg |
|||
